Polyester Polyols Resin Tank Reactor Mixer
- Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Type | Reaction Kettle | Place of Origin | Shanghai, China | |
| Brand Name | SIEHE | Model Number | SFJB | |
| Voltage | 380v, 220v, 440v, 110V, 415V, various option | Power(W) | 2.2KW- 110KW | |
| Dimension(L*W*H) | According to the capacity | Weight | According to the capacity | |
| Certification | CE, ISO, SGS | Warranty | 12 months warranty and lifelong service | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Polyester polyol resin reactor mixer
Reactor is a kind of atmospheric pressure or pressure vessel that is applicable for petroleum, chemical, rubber, pesticide, dyestuff, medicine, food and other industries, and used to complete the process of vulcanization, nitration,hydrogenation, alkylation, polymerization, condensation, also called polymerization reaction kettle, reactor, decomposition kettle, etc.; the material usually adopts carbon manganese steel, stainless steel, zirconium, nickel based (Harrington, Meng Naier, Kang Nie) alloy and other composite materials. Siehe company mainly produce the stainless steel reactor and carbon manganese steel reactor.
All-in-one Design with Heating, Cooling, Dust Collecting and Condensing
Siehe industry has many years’ experience of reactor application, and capable of realizing the functions of heating, cooling, thermal insulation, mixing reacting, dust collecting and condensing & refluxing within one reactor, meet the requirement of high integration, improve the production efficiency and reduce the cost.
Diverse Structure
Siehe reactor, according to structure, can be divided into: open flat cover type, open flange type and closed type;
According to pressure, can be divided into: atmospheric pressure type, negative pressure type, positive pressure type, positive and negative pressure type;
According to heating and cooling mode, can be divided into: jacketed type, coil pipe type, outer jacket and inner coil pipe type, inner and outer coil pipe type;
The agitator type is diverse, according to the materials feature;
Non-Standard Customizing, Complete Production Line Designing
Usually design the complete production line according to the output, production process, processing time, etc.
Model | Power(kw) | Speed | Agitator | Equipment Material | Capacity(L) | Weight |
SJBF-1.1 | 1.1 | 100rpm | Anchor type, paddle type, frame type and other types of agitators don’t share the same data regarding the viscosity application, speed, power, etc. | Contact part SS304 | ≤200 | 250 |
SJBF-1.5 | 1.5 | 85rpm | Contact part SS304 | ≤300 | 250 | |
SJBF-2.2 | 2.2 | 76rpm | Contact part SS304 | ≤500 | 300 | |
SJBF-3.0 | 3.0 | 67rpm | Contact part SS304 | ≤800 | 350 | |
SJBF-4.0 | 4.0 | 63rpm | Contact part SS304 | ≤1000 | 450 | |
SJBF-5.5 | 5.5 | 59rpm | Contact part SS304 | ≤1500 | 350 | |
SJBF-7.5 | 7.5 | 59rpm | Contact part SS304 | ≤2500 | 450 | |
SJBF-11 | 11 | 53rpm | Contact part SS304 | ≤3000 | 350 | |
SJBF-15 | 15 | 53rpm | Contact part SS304 | ≤4000 | 450 | |
SJBF-18.5 | 18.5 | 53rpm | Contact part SS304 | ≤5000 | 350 | |
SJBF-22 | 22 | 43rpm | Contact part SS304 | ≤8000 | 450 | |
SJBF-30 | 30 | 43rpm | Contact part SS304 | ≤10000 | 350 | |
SJBF-200 | 200 | Non-standard | Non-standard | Contact part SS304 | non standard | non standard |
Please contact with us or check our webisite for more models.
