aluminum extrusion profile
- shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Grade | 6000 Series | |
| Temper | T3-T8 | Application | Decorations | |
| Shape | T - Profile | Alloy Or Not | Is Alloy | |
| Model Number | HTN | Brand Name | HH |
Product Description
Specifications
aluminum profile with any Colour:Powder coated or anodizeAlloy:6063,6061,6082,6060,6005
T4,T5,T6,F
ISO9001 IS1
Hai Hong Aluminum profile is a famous band in China
Construction field for window,door,curtain wall,railing,etc
We have Anodizing,powder coating,eletrophoresis
We are able to provide aluminum extrusion(aluminum profile) with different surface treatment by the aid of most advanced equipment including :
17 extruding presses
4 aging oven
2 anodizing lines
2 powder coating lines,maximum length to 12 meters
Aluminum Alloy profile of 6063,6061,6082 according to GB-T/5237.1-2000
Anodizing according to GB/T523.7-2000 for interior and exterior applications
· silver
· gold
· Champagne
· bronze
· black
Specification:
| Alloy | Si | Mg | Fe | Cu | Mu | Zn | Cr | Ti | Impurity | Al | |
| unit | total | ||||||||||
| 6063 | 0.20-0.60 | 0.45-0.9 | ≤0.35 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.05 | ≤0.15 | Surplus |
| 6063A | 0.30-0.60 | 0.60-0.90 | 0.15-0.35 | ≤0.10 | ≤0.15 | ≤0.15 | ≤0.05 | ≤0.10 | ≤0.05 | ≤0.15 | Surplus |
| 6061 | 0.40-0.80 | 0.80-1.2 | ≤0.70 | 0.15-0.40 | ≤0.15 | ≤0.25 | 0.04-0.35 | ≤0.15 | ≤0.05 | ≤0.15 | Surplus |
Anodizing of aluminum profile(aluminum alloy profile)
Grade | Average thickness /µm,not less than | Local thickness/µm,not less than |
AA10 | 10 | 8 |
AA15 | 15 | 12 |
AA20 | 20 | 16 |
AA25 | 25 | 20 |
The anodic film of the profiles is generally supplied in grade AA10 or is controlled per customers request.
Eletrophoresis of aluminum profile(aluminum alloy profile)
Grade | Anodic oxidation film | Lacquer iflm | Composite film | |
| Average thickness/µm | Local thickness/µm | Local thickness/µm | Local thickness/µm |
A | ≥10 | ≥8 | ≥12 | ≥21 |
B | ≥10 | ≥8 | ≥7 | ≥16 |
The electrical film of the profiles is generally supplied in grade B or is controlled per customers request
The packing of the aluminum extrusion(aluminum profile) could be customized according to your requirement
