Tractor 3-point-link wood shredder
With CE certificate.
Both hydraulic feeding and mechanical feeding.

3-point-link Wood Shredder

1. Tractor rear 3-point-link, driven by PTO

2. Max. 8 inch (200mm) chipping diameter

3. 6-9CBM/hour working capacity

4. Discharge hood can rotate in 360 degrees

5. Feeding system: mechanical roller feeding or hydraulic motor feeding optional

6. CE certificate

Model		WC-8
Max dia. Of feeding	mm	200mm(8")
Power	hp	Tractor(25-45hp, PTO 540/720rpm)
Flyweel Dia.	mm	600
Flyweel turning speed	rpm	1120/1490
Feeding system		Hydraulic feeding,adjustable speed,
Feeding system		stop-reverse-forward function
No.of blade		2 or 4( suggest 2 )
Sawdust measurement	mm	thickness max 4mm
Feeding outlet rotation angle		360⁰
Structure weight	kg	450
Working efficiency	m³/h	8~9
Hydraulic oil tank	Liter	38
Packing size(LWH)	mm	11509001350
