4-wheel drive bus
- 2000 Set / Sets per Month
- qingdao
- T/T
You May Like
Product Details
| Capacity (Load) | 1 - 10t | |||
| Drive Wheel | 4x4 | Horsepower | Other, < 150hp | |
| Transmission Type | Manual | Emission Standard | Euro 2 | |
| Fuel Type | Diesel | |||
| Place of Origin | Shandong, China | Brand Name | Heto | |
| Model Number | EQ6689PT |
Product Description
4-wheel drice bus
4x4 Specification of Dongfeng EQ6689PT COUNTRY-CROSS BUS
Overall Dimensions | 6700* 2240 * 2670 |
Length(mm) | 6700 |
Width(mm) | 2240 |
Height(mm) | 2670,2950 With Outer Luggage rack |
Interior height(mm) | 1680 |
Wheelbase(mm) | 3650 |
Tread Front/Rear(mm) | 1774/1774 |
Front/Rear Overhang(mm) | 1290/1760 |
Min. Ground clearance | 286 |
Approach/Departure Angle(o) | 35/23 |
Brake distance (v fully loaded) | ≤10 |
Fuel consumption (L/100km) | 12 |
Max. Total Mass | 6500 |
Front/Rear Axle (kg) | 3000/3500 |
Max. Speed (km/h) | 80 |
Max. Grade ability (%) | 55 |
Min. turning circle diameter (m) | 16 |
Fuel Tank Capacity (L) | 60/135(main tank) |
Engine |
|
Arrangement of Engine | Four cylinder in line |
Model | EQB140-30 140hs Dongfeng Cummins diesel engine |
|
|
Position | Front |
Displacement (L) | 3.92 |
Bore X stroke (mm) | /102×120 |
Compression Ratio | 17.3:1 |
Max. Output (kw/rpm) | 92/2800 |
Max. Torque (N.m/rpm) | 410/1400-1600 |
Type of Fuel | Diesel |
Chassis |
|
Model | EQ6689KS |
VIN | LGKY9CCG |
Clutch | Single,dry,diaphragm spring clutch 330 |
Gearbox | Dongfeng brand |
Technology and model | Mechenical Manual,Five forward Gear with one Backward Gear;Model: 17S26B-0030 |
nr. of speeds | 1:6.30,2:3.71,3:2.11,4:1.32,5:1,R:6.6 |
Rear axle | Single Class Speed Reduction;Welding Chaissis Casing;EQ153;Load Mass:11 Tons |
Front axle | I-shape beam Frame |
Frame | Dongfeng frame:28 6-00010/41T |
Suspension system | Strengthen spring 9/11 |
Steering system | Chinese power steering gear |
Braking system | Front&Rear drum,dual-circult service brakding system |
Tyre | 11R18 |
Electric system | 24V minus earth |
Starter | 24V 4.5KW |
Battery/Alternator | 12V-2/28V 70A |
Body |
|
Body structure | Standard of dongfeng |
Type of floor | PVC plat-floor PVC floor |
Inner decorating | Standard |
Door and door pump | general door ,Pump type:FR803 |
Windows | Standard |
Emergence exit | 3 |
Nr.Seats (standard/optional) | 19 |
Air-conditioning system | Optional(Dongfeng Paninco brand) |
Heating system | Heater by hot water |
Audio and Visual system | Optional |
Services facilities | Not |
Others | Optional |
Electronic station displayPortuguese | Standard |
Counting passenNger system(entry /exit | Not |
Engine intercooling system | Turbocharged and Aftercooled |
Running recorder | Made in China |
Coin box with protection | Not |
Metal plaint | Standard |
Soft dashboard : | Standard |
Luggage compartment | Standard |
Fire extinguisher | Standard |
VDO sensor VDO | Standard |
AC system AC | option |
