GE DS200SDCCG1AFD Placa de Controle de Acionamento – Cart?o de Controle Central para Sistemas DC2000/AC2000/EX2000

• Controlador primário da unidade de acionamento – Coordena os loops de velocidade/par e a lógica geral da unidade de acionamento para o GE DC2000/AC2000/EX2000.

• Entrada/Saída de sinal misto – Aceita referências e feedback analógicos (normalmente ±10 V ou 4–20 mA via condicionamento) e sinais discretos de 24 VDC, em seguida, envia referências de controle para as placas de potência e de entrada/saída.

• Comunica??es industriais – Fornece acesso serial de servi?o/diagnóstico (comumente RS?232) e um link do estilo RS?485 usado dentro do gabinete da unidade de acionamento.

• Aprimoramentos da revis?o “AFD” – Revis?es posteriores de arte/funcionais que, em muitos casos, melhoram a estabilidade e a intercambiabilidade dentro da série G1.

• Design amigável ao servi?o – Conectores plugáveis e conectores de fita facilitam as substitui??es durante paradas planejadas.

• Constru??o n?o conforme (série DS200) – Normalmente fornecida sem revestimento conforme, tornando a inspe??o e a reparo no campo mais diretos.

• DS200DCFBG1A – Drive Control Feedback Board (conditions analog feedbacks, often mated to SDCC)

• DS200DTBA / DS200DTBB – Terminal boards for discrete I/O terminations

• DS200DSPCG / DS200SDRM – Signal distribution or protection interfaces depending on cabinet design

One thing I appreciate is how the SDCC keeps swap?outs predictable: when you carry over the original firmware set and retain the same daughter connectors, downtime stays short. A maintenance lead at a paper mill told me their team swapped an SDCC during a 4?hour window and were back to production with only a quick loop tune.

This board is a fit for medium?to?large GE drive cabinets where reliable closed?loop control is mandatory. You’ll often see it in:

• Metals processing – mill stands, coilers, unwinders needing tight torque control

• Pulp & paper – sectional drives on winders, coaters, and calendar stacks

• Power generation – exciters (EX2000) for generators

• Oil & gas / mining – conveyors, compressors, and pump drives

• Water & wastewater – high?horsepower blowers and pumps

• Reliability – Proven in harsh industrial duty; the AFD revision seems to add tolerance to electrical noise in many cases.

• Compatibility – Drop?in for many G1 builds when firmware and optioning match; reduces re?engineering risk.

• Lifecycle savings – Keeps legacy DC2000/AC2000/EX2000 assets running, deferring multi?million cabinet replacements.

• Technical support – We can help verify firmware part numbers, connector population, and quick commissioning steps.

• Cabinet environment – Install in a clean, ventilated enclosure; maintain airflow around boards. Keep ambient 0–60 °C, non?condensing.

• Wiring & grounding – Observe drive grounding schemes. Route low?level analog away from high?frequency power cables to minimize noise pickup.

• ESD precautions – Handle with a grounded wrist strap; power down and wait for DC bus discharge before removal.

• Firmware transfer – Move the original firmware devices (EPROMs/Flash daughter parts, if present) from the old board to retain application behavior.

• Routine care – Annual dust cleaning with dry air; check ribbon connectors for oxidation; verify analog calibration and update drive firmware when recommended by site standards.

• Typically CE and UL compliant at the system level when installed in GE drive cabinets

• Manufactured under GE quality systems; ISO-based factory processes

• RoHS status may vary for legacy builds; muitas instala??es anteriores à obrigatoriedade da RoHS

• Garantia: 365 dias
