ALSTOM MVAW11B1AB9007A – Auxiliary Protection Relay for Trip/Interlock Duties in Power Systems

• Hardwired reliability – Pure electromechanical design with no firmware; in many cases preferred for critical trip/interlock tasks.

• Single changeover output – MVAW11 series is commonly configured with one Form C (SPDT) contact for simple, robust control logic.

• DC coil variants – Typically offered in 110 VDC or 220 VDC coils (other DC voltages exist in the family), helping match existing panel supplies.

• High contact rating – Suited for breaker trip coil duty and signal duplication; seems to handle resistive loads comfortably in utility panels.

• Panel-friendly mounting – Designed for protection cubicles and switchgear doors; straightforward wiring and maintenance.

• Noise-tolerant operation – Good immunity to substation noise compared with sensitive electronic inputs.

You might notice that utilities and EPCs keep these relays on BOMs for the “must-work” links in a scheme. Typical uses include:

• Substation breaker tripping and closing interlocks

• Signal duplication and galvanic isolation for SCADA/RTU inputs

• Lockout, blocking, and permissive logic in protection panels

• Turbine/generator and plant auxiliaries where a dedicated hardware relay is preferred

• Process safety tie-ins where fail-safe, visible hardwiring is requested

• Dependable sourcing – Helpful for maintaining legacy ALSTOM/GEC protection panels without redesign.

• Compatibility – Works cleanly with DC trip circuits, MiCOM/Agile relays, and common RTU I/O—no protocol headaches.

• Lifecycle savings – Minimal commissioning effort and practically zero firmware maintenance.

• Support – We can cross-check coil voltage, contact arrangement, and mounting details by serial to avoid misorders.

Customer feedback (utility O&M lead): “We swapped an older auxiliary with an MVAW11 unit last outage—wiring matched our drawing, and trip timing stayed consistent. It’s been trouble-free.”

• Panel/cabinet – Install in a clean, dry IEC-rated enclosure with basic ventilation. Keep DC supply within the specified coil range.

• Wiring – Use ferruled, labeled conductors; segregate DC trip wiring from high-noise conductors where practical. Verify polarity on DC coils.

• Commissioning – Perform a contact continuity check, coil pickup test at nominal and at -10%/-15% supply if required by site procedures.

• Routine maintenance – Periodic functional trip checks; inspect terminals for looseness; clean dust with dry air; replace if contact wear or discoloration is evident.

• Safety – Isolate DC supplies, verify zero energy, and tag before handling. Where fitted, observe arc-suppression networks across coils.

• Manufactured within ALSTOM/GE Grid Solutions quality systems (typically ISO 9001)

• CE marking customary for EU markets; RoHS applicability depends on production year and configuration

• Utility-proven electromechanical design with long field history

• Standard warranty: 365 days
