ABB 5SHX1060H0003 (3BHE024415R0101) IGCT Gate Unit – Reliable Drive for High?power IGCT Stacks

• Warranty: 365 days coverage

• Lead time: 1 week if in stock; no more than one month at the latest

• Payment terms: 50% advance payment; full payment prior to delivery

• Express options: FedEx, UPS, DHL

• Dedicated IGCT gate drive – Provides the high-current, fast-rising gate pulses IGCTs need for clean turn-on and robust turn-off.

• Fiber?optic command interface – Optical Rx/Tx links for noise?immune firing commands and status feedback, ideal for MV switchrooms.

• Integrated protection – Includes typical desaturation/overcurrent monitoring and fault signaling to help protect the device and stack.

• Isolated power architecture – Internal DC/DC isolation separates control from power, improving safety and EMC behavior.

• Drop?in service part – Intended as a like?for?like replacement in ABB converter stacks; reduces commissioning time after maintenance.

• Industrial temperature operation – Built for cabinet environments in MV drives and utility?scale converters.

Note: Exact ratings and mechanical dimensions can vary by stack design and drive family. If you share your drive typeplate or stack code, we’ll match the correct revision to avoid downtime.

• Medium?voltage drives for cement, mining, oil & gas, metals, and marine propulsion

• Utility and industrial power converters: STATCOM/SVC, large UPS, and grid converters

• High?power test benches and regenerative load systems

• Reliability – Stable gate energy and fast protection seems to be the main reason maintenance teams prefer this ABB unit in retrofit work.

• Compatibility – Matches ABB IGCT stacks typically used with devices such as 5SHY series IGCTs; minimizes engineering changes.

• Cost control – Reduces unplanned downtime; a direct replacement often avoids rewriting control firmware or fiber mapping.

• Support – We can pre?check your stack code and fiber pinout to ship the correct revision, which cuts on?site time.

• Cabinet environment – Install in a clean, ventilated MV drive cabinet; allow adequate airflow around the unit and snubber components nearby.

• Wiring – Use the designated 24 VDC supply (regulated); verify polarity and protective earth. Route fiber?optic links separately from power cabling.

• Mechanical fit – Mount securely to the IGCT stack/bracket; confirm creepage/clearance are not compromised by nearby busbars.

• Safety – De?energize the cabinet, discharge DC link, and follow lockout/tagout. IGCT stacks retain energy; handle with HV PPE.

• Routine checks – Inspect fiber connectors for dust, confirm connectors are fully seated, and check gate?drive health LEDs/fault logs.

• Firmware/config – Some installations require parameter alignment at the drive control board; keep a backup of the working set before swap.

• Manufactured under ISO 9001 quality management (ABB production)

• RoHS conformity typically met for electronic assemblies in this class

• CE/UL assessment is usually at the system level; this gate unit is a component within MV converters

• Warranty: 12 months (per above terms)

This gate unit is typically paired with ABB press?pack IGCTs (e.g., 5SHY series) and their snubber networks. You might notice better reliability when you replace aged fibers and check snubber capacitors at the same time. We can also supply matching fiber?optic transmitter/receiver boards and stack accessories on request.
