Perkins engine 1104D-44T (NL75383) power 62.5KW

The Perkins engine 1104D - 44T is a model in the Perkins 1100 series, featuring reliable performance and wide - ranging applications. Here is an introduction: ### Basic Information - **Manufacturer**: Perkins. - **Cylinder Arrangement**: In - line four - cylinder. - **Displacement**: 4.4 liters. - **Bore and Stroke**: 105 mm in bore and 127 mm in stroke. - **Compression Ratio**: 18.2:1. - **Cooling System**: Liquid - cooled. - **Dimensions**: Approximately 1277 mm in length, 687 mm in width, and 965 mm in height. - **Dry Weight**: About 536 kg. ### Technical Characteristics - **Intake Method**: Turbocharged, which can increase the air intake volume, improve combustion efficiency, and enhance power output. - **Combustion System**: Adopts a direct - injection combustion system, which can make the fuel burn more fully, improving engine efficiency and reducing emissions. - **Fuel Injection System**: It provides a choice of mechanical or electronically - controlled common - rail engines. The electronically - controlled common - rail system can adjust the fuel injection quantity in real - time according to the engine load, achieving precise control. - **Maintenance Features**: The service interval is 500 hours, and the components are serviced on a single side, which is convenient for end - user maintenance. ### Performance Parameters - **Power Output**: The maximum power is 66 kW (88.5 hp) at 2200 rpm, and the minimum power is 58.5 kW (78.4 hp). - **Torque**: The maximum torque is 392 N·m at 1400 rpm. ### Emission Standards The engine complies with EU ECE R96 Stage IIIA and China Non - road Stage III emission standards, with lower exhaust emissions and better environmental performance. ### Applications The Perkins 1104D - 44T engine is widely used in various fields. It is used as the power source for forklifts in the warehousing and logistics industry. In the agricultural field, it drives agricultural machinery such as large tractors and combine harvesters. It also provides power for heavy - equipment such as loaders and excavators in construction sites.
