SIGLENT SDS5034/SDS5054/SDS5104X Digital Oscilloscope, 4 Channels, 5G Sample Rate

SIGLENT’s SDS5000X series Digital Storage Oscilloscopes  are available in bandwidths of 1 GHz, 500 MHz and 350 MHz,  have a maximum sample rate of 5 GSa/s, maximum record  length of 250 Mpts/ch, and display up to 4 analog channels +  16 digital channels mixed signal analysis ability. The SDS5000X series employs Siglent’s SPO technology with  a maximum waveform capture rate of up to 110,000 wfm/ s  (normal mode, up to 500,000 wfm/s in Sequence mode), 256- level intensity grading display function plus a color temperature  display mode. It also employs an innovative digital trigger  system with high sensitivity and low jitter. The trigger system  supports multiple powerful triggering modes including serial  bus triggering. History waveform recording, Sequence  acquisition, Search and Navigate functions allow for extended  waveform records to be captured, stored, and analyzed. An  impressive array of measurement and math capabilities,  options for a 25 MHz arbitrary waveform generator, as well as  serial decoding are also features of the SDS5000X. The large 10.1’’ display capacitive touch screen supports multitouch gestures, with the addition of user-friendly one-button  design for most commonly used functions, can greatly improve  the operation efficiency of the SDS5000X. It also supports  mouse and external keyboard control.
