On Grid Photovoltaic Energy Storage Integrated System 50KW/100WKH SRM-E215-100K-400-L

FOB Price

US$ 21500

≥1 Sets

Port Shenzhen
Payment TermsT/T
Delivery Detail30 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Certification	CE	Warranty	1
Application	Home, Industrial, Commercial, Other	Specification	Normal
After-sales Service	1	Condition	New
Transport Package	Yes	Trademark	solaroom
Origin	China

Product Description

1、Flexible matching,supporting the parallel use of multiple units in 1+N mode;

2、High power density,compact size,small footprint,and convenientinstallation and transportation;

3、Support photovoltaic access and match distributed MPPT controller;

4、Optional off-grid switching components are available to realize uninterrupted power supply after power outage;

5、4G,WIFI online intelligent monitoring,remote inspection,reducing on-site manual inspection tasks;

6、Deploy on demand,operate automatically during peak shaving valley filling,support linkage control of BMS,PCS and EMS systems,and have multiple protections;

7、The battery is liquid-cooled,with refined constant temperaturecontrol and management,small cell temperature difference and longlife;

8、Pack level+whole cabinet fire protection,perfluorohexanonerapid fire extinguishing,high safety and reliability.

Product Model		SRM-E215-100K-400-L
DC Battery	Cell type	LFP 280Ah
	Battery Pack capacity and configuration	43.008kWh/1P48S
	Battery capacity/number of packs	215kWh/5
	Battery voltage range	672V~864V
	Charge and discharge rate	≤0.5C
	Discharge depth	95%DOD
	Cycles	＞8000
	Numberof temperature checks	160
PV Side	Maximum input power	100kW
	Maximum input current	148A
	Voltage range	672V~864V
AC Side	AC rated power	100kW
	AC maximum power	110kW
	AC current distortion rate	<3%
	DC component	<0.5%lpn
	System voltage format	400V
	Grid voltage range	360VAC~440VAC
	Power factor	-1~1
	Rated grid frequency	50Hz/60Hz
System Parameters	Maximum system efficiency	≥89%
	Operating temperature	-30~55℃(Derating when exceeding 40 degrees Celsius)
	Relative humidity	0 to 95%RH,no condensation
	Dimensions (LxDxH)	1050×1300×2250mm(including hanging rings)
	Weight	2400kg
	Protection level	IP54 (IP67 for battery)
	Noise	<70dB
	Cooling method	Battery liquid cooling,PCS air cooling
