Home > Products > Industrial Pipeline Series > Hot Cold Rolled Ss 304 304L 316 316L 321 ISO TUV PED SGS Stair Railing Round/Square Alloy /Galvanized/Stainless Seamless Welded Steel Tube Pipe
Hot Cold Rolled Ss 304 304L 316 316L 321 ISO TUV PED SGS Stair Railing Round/Square Alloy /Galvanized/Stainless Seamless Welded Steel Tube Pipe
- 0 Ton / Tons per Month
- T/T
- 8 days
You May Like
-
Factory Supply Ss201 202 304 316 316L 430 420 J1 J2 440c Stainless Steel Pipe/Tube Seamless/Welded Pipe
-
Stainless Steel Boiler Heat Exchanger Tube, Seamless Tube for Pressure Vessels
-
AISI ASME ASTM 304 316 321 Stainless Steel Plate with White Surface
-
ASTM A213 TP304/304L/1.4301 Sanitary Grade Stainless Steel Pipe Tube
-
304 Stainless Steel Casting Parts Stainless Steel Round Bar Duplex Stainless Steel Rods and Bars
-
201 210 303 310 316 340L 409 416 420 431 440c 630 SUS 401 416 316lvm Stainless Steel Round Bar Rod
Product Details
Certification | ISO | Shape | Round | |
Technique | Cold Rolled | Model NO. | 201, 303Cu, 304, 304L, 316, 316L, 310S, | |
Production Process | welding/ polishing/inside bead removing | Specification | Customized |
Product Description
Classification of stainless steel pipe: stainless steel seamless steel pipe and stainless steel welded steel pipe (seam steel pipe) basic two categories. According to the outer diameter shape of steel tube can be divided into round tube and special-shaped tube, what is widely used is circular steel tube, but also have a few square, rectangle, semicircle, hexagonal, equilateral triangle, octagonal special-shaped steel tube.
For the steel pipe under fluid pressure to carry out hydraulic test and ray flaw detection to test its pressure ability and quality, under the specified pressure does not leak, wet or expansion for qualified, some steel pipe according to the standard or the requirements of the side test, flaring test, flattening test.
Specification:
A:Stainless steel seamless pipe:
Standard:ASTM A312 Austenitic Stainless Steel Pipes for high-temperature and general corrosive service.
ASTM A213 for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A269 Austenitic Stainless Steel Tubes for General Service
ASTM A270 for Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubes
Grade:
TP304,TP304L,TP304H,TP316,TP316L,TP316Ti,TP309,TP310S,TP321,TP321H,
TP347, TP347H, TP405, TP410, TP430
Sizes: 1/8" - 36" +
Schedules: S/5s - XXS
Services: Bending - Cutting - Grooving - Polishing - Threading
Surface treatment: Industrial tubes Annealed and pickled, Sanitary tubes polished 180 grit, 240 grit, 400 grit
Austenitic steel
TP304 | General-purpose stainless steel with good corrosion resistance for most applications. Used for: Bar rails, Boat railings, Canopy supports, Chemical processing equipment, Chemical tubing, Column covers, Duct works, Feed-water tubes, Food preparation equipment, Food processing equipment, Heat exchanger tubes, Hypodermic needles, Ladders, Mechanical & structural components, Pharmaceutical processing equipment, Piping systems, Railings (architectural), Traffic barriers, Water pipes. |
TP304H | Higher carbon content than 304L, for increased strength, particularly at elevated temperatures. |
TP304L | Chemical plant and food processing equipment, where freedom from sensitization is required in plate thicknesses TP316/316L |
TP316/316L | Used where higher corrosion resistance is required. Boat railings, Canopy supports, Chemical tubing, Column covers, Duct works, Feed-water tubes, Food preparation equipment, Food processing equipment, Heat exchanger tubes, Hypodermic needles, Ladders, Mechanical & structural components, Pharmaceutical processing equipment, Piping systems, Railings, Street (urban) furniture, Textile tubing, Traffic barriers, Water pipes. |
TP316H | Similar oxidation resistance to TP 316. Main areas of application: Heat exchangers, furnaces, chemical and petrochemical plant. |
TP321 | Heat exchanger tubing, Chemical processing tubing, Pressure tank tubing. Suitable for heat resisting applications to 800°C. |
TP321H | This is the high carbon version of TP 321 which ensures greater creep resistance. Behaves much the same as TP 321 in oxidation resistance. Main applications: Heat exchangers, furnaces, boilers in chemical and petrochemical plant |
TP316Ti | A titanium stabilized version of 316 used where good resistance to intergranular corrosion and high temperature strength is required. |
TP317 | Chemical processing tubing, Dyeing equipment, Ink manufacturing equipment, Pulp & paper manufacturing equipment |
TP347HFG | Mainly used for boilers in the termal power plant, reheaters and superheaters |
Super-Austenitic steel
TP904L
High resistance to general corrosion in e.g. sulphuric and acetic acids, crevice corrosion, stress corrosion cracking, pitting in chloride bearing solutions.
Ferritic and Martensitic Steel
TP405 | Used for applications where hardening upon cooling from high temperatures must be avoided. Has excellent long-time stability up to 1200°F. |
TP410 | General purpose grade for use in mildly corrosive environments |
TP430 | Mechanical & structural tubing, Architectural tubing, Heat exchanger tubing, Condensers, Re-heaters, Evaporators. |
Duplex
S31803 | Typically used in heat exchangers, gas scrubbers, fans, chemical tanks, flowlines, marine and refinery applications. |
S32750 | Used in oil & gas, chemical process, power industries. At that heat-exchangers are main application. |
S31254 | With high levels of chromium, molybdenum, and nitrogen is especially suited for high-chloride environments such as brackish water, seawater and other high-chloride process streams. |
Value-added services
BEVELING
Beveling Stainless Steel tubes contain one end angled, so that it mates with a complementary tube end. Tubes can be beveled for certain applications in order to make welding of stainless steel tubes easier, which saves weld prep time and money compared to hand cutting.
HEAT TREATING & ANNEALING
Permanent Steel can heat treat some 400 series stainless steel seamless tube. Heat treating realizes stress as a result of hardening, depending upon the chemistry of the metal being treated. Heat treating is also used for tempering, quenching, normalizing, and solution annealing.
HONING & TURNING
During the honing/turning process, an abrasive rotating tool removes metal from the interior surface of a cylinder, pipe, or tube. The main purpose of honing is to finish the surface to a particular diameter and/or desired cylindrical geometric design. Honing is typically a secondary machining operation that completes a produce/part, relieves stress created during production, or corrects features of the finished product. A typical production cycle is to drill, ream, heat treat, then hone.
POLISHING
POSITIVE MATERIAL IDENTIFICATION (PMI)
In some cases, it may be necessary to complete additional positive material identification testing. Permanent Steel can complete this testing in house or we can work with an independent laboratory to complete the testing. Please contact us for specific requirements.
UT TESTING
Ultrasonic Testing (UT) utilizes sound energy at high frequencies, in order to provide examinations and measurements of the stainless steel product. This aids in flaw detection/evaluation, dimensional measurements, etc.B:Stainless steel welded pipe:
Sizes & Schedule Specifications
Size Range: 2" - 48"
Schedules: 5S, 10S, STD, XS, 40, 80, 100, 120, 160, XXS
Products: Stainless steel welded pipe, stainless steel erw pipe, stainless steel efw pipeGrades of Stainless Steel Tube
Austenitic: 201, 304/304L, 316/316L, 317/317L, 347/347H, 321/321H, 904L
Ferritic: 409, 430, 439, 441, 434, 436, 444, 446
Martensitic: 403, 410, 410S, 414/L, 441, 418, 420, 440, 416
Duplex: 2205/S31803, S32750, S32760
Manufacturing process:
Stainless steel welded tube is a steel pipe made of steel plate or strip steel that is crimped and formed by a unit and a mold. The production process of welded steel pipe is simple, the production efficiency is high, the variety and specification are many, and the equipment investment is small, but the general strength is lower than that of seamless steel pipe.
Processing for Stainless Steel Welded Pipe
Bar & Structural Cutting | Products cut include Round Bar, Flat bar, Hex bar, Square bar, Tubing and Hollow Bar, Pipe, Angles, channels, Beams and Tees. Thickness range is 1/16″ to 28″diameter |
Production Cutting | Stainless can provide production cutting for product diameters up to 4″. |
Pipe Threading | Available thru 2″ in Diameter/All schedules |
Tubular Polishing | Products polished included all tubular products, with OD & ID polishing available, Round Bar, Square Bar, Hex & Flat bar, Angles, Uneven Leg Angles, beams, and other shapes. |
Welded Stainless Steel Pipe Tolerances
NPS Designator | Permissible Variations in Outside Diameter | |
Over In. | Under In. | |
1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Nominal Wall Thickness:
NPS Designator | Outside Diameter in. | Schedule 5S in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. |
1/4 | 0.540 | 0.065 | 0.088 | 0.119 | |
3/8 | 0.675 | 0.065 | 0.091 | 0.126 | |
1/2 | 0.840 | 0.065 | 0.083 | 0.109 | 0.147 |
3/4 | 1.050 | 0.065 | 0.083 | 0.113 | 0.154 |
1.0 | 1.315 | 0.065 | 0.109 | 0.133 | 0.179 |
1 1/4 | 1.660 | 0.065 | 0.109 | 0.140 | 0.191 |
1 1/2 | 1.900 | 0.065 | 0.109 | 0.145 | 0.200 |
2 | 2.375 | 0.065 | 0.109 | 0.154 | 0.218 |
2 1/2 | 2.875 | 0.083 | 0.120 | 0.203 | 0.276 |
3 | 3.500 | 0.083 | 0.120 | 0.216 | 0.300 |
3 1/2 | 4.000 | 0.083 | 0.120 | 0.226 | 0.318 |
4 | 4.500 | 0.083 | 0.120 | 0.237 | 0.337 |
5 | 5.563 | 0.109 | 0.134 | 0.258 | 0.375 |
6 | 6.625 | 0.109 | 0.134 | 0.280 | 0.432 |
8 | 8.625 | 0.109 | 0.148 | 0.322 | 0.500 |
10 | 10.750 | 0.134 | 0.165 | 0.365 | 0.500 |
12 | 12.750 | 0.156 | 0.180 | 0.375 | 0.500 |
C:Stainless steel decorative pipe:
ITEMS | Stainless steel decorative pipe | |||
Stainless welded pipe(round) | Stainless square pipe | Stainless rectangle pipe | Stainless oval pipe | |
OD range | 3-219MM | 10MM*10MM--100MM*100MM | 20*10MM--100*200MM | 5*48MM 38*15MM 39.8*20.8MM 44*16MM etc.. |
WT range | 0.12-4MM | 0.16-4MM | 0.16-4MM | 0.23-4MM |
Length range | Normal length 3-6M,but can be custom-made as requirements. | |||
Grade | 304/301/201/202/316/430/410/420/409etc. | |||
Surface treatment | Matte(usually used as industrial pipe)/Mirror finish(decoration pipe) |
D:Stainless slotted tubes::
Johnson screen/ore screen mesh | Grade:201/202/205/304/316/321 etc... Shape:Cylindric,flake Cylinder Diameter:29-1000mm Slot size:0.5-1.0mm in usual, can be customized Filter type:from outside to inside Length:2.9m or5.8m in usual to fit the container End connection: Male/female threaded couplings, weld rings/plain beveled |
Wire-wrapped screen/strainer | Grade:201/202/205/304/316/321 etc... Size:2-16inch Slot size:0.5-1.0mm in usual, can be customized Length:2.9m or5.8m in usual to fit the container End connection:Male/female threaded couplings, weld rings/plain beveled |
E:Stainless steel coil:
Thickness: 0.20-10.00mm
Width: 1000-1500mm
Grade: 304(2B),304(No.4),304(BA),304(HL),304(MR)316/L(2B),316(No.4)
F:Stainless steel sheet:
Thickness: 0.40-8.00mm
Width: 1000-1500mm
Grade: 430, 304 and 316. Grade types such as 409, 410, 444, 309, 310s, 321, 347, 321, 904L, 2205, 2304, 316Ti, 316H, 317L
G:Stainless steel plate:
Thickness:3.00-32.00mm
Width: 1000-1500mm
Grade: 304L, 316L, 904L, LDX2101, 2205,409, 410, 309, 310s, 321, 347, 321, 2304, 316Ti, 316H, 317L
H:Stainless steel squre pipe:
Out diameter:12.70-150mm
Width: 1.0-3.5mm
Grade:304, 304L,304H, 316, 361L,316H, 309/S, 310/S, 317/L, 321/H, 347/H, 410, 410S, Duplex 2205, Duplex 2507
Specifications: ASTM A312, ASTM A358, ASTM A240, ASTM A778
I:Stainless steel rectangle pipe:
Out diameter:24.0*14.0mm-100*50.8mm
Width: 1.0-5.0mm
Grade:304, 304L,304H, 316, 361L,316H, 309/S, 310/S, 317/L, 321/H, 347/H, 410, 410S, Duplex 2205, Duplex 2507
Specifications: ASTM A312, ASTM A358, ASTM A240, ASTM A778
J:Stainless steel fittings:
Flange, elbow,tee,reducer,cap,weldolet,bend,socket etc..
Application:
About us:
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from ?Φ?6 to?Φ?762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from ?Φ?15 to ?Φ?2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
1. We have high-quality products, which are directly supplied by the factory to ensure adequate supply.
2. We provide professional services to solve your problems online 24 hours a day.
3. With years of supply experience, we strive to bring value to every customer.
Company Profile

Zhongzheng Stainless Steel Co., Ltd. is a China-based manufacturer specializing in R&D, production, and distribution of stainless steel products. Established in the early 2000s, it serves industries including construction, machinery, food/medical equipment, and energy with precision tubes, sheets, profiles, and custom components.
