Home > Products > Steel coil sheet and plate > Stainless Steel Sheet 304 304L Stainless Steel Plate / Stainless Steel Sheet 316 316L

Stainless Steel Sheet 304 304L Stainless Steel Plate / Stainless Steel Sheet 316 316L

FOB Price

Negotiable / Ton

100000 Tons(Min.Order)

Supply Ability 0 Ton / Tons per Month
Port TIANJIN
Payment TermsT/T
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other	Shape	Other
Color	Titanium Gold	Surface Treatment	Other, Coated
Transport Package	Standard Export Seaworthy Package, or as Required	Specification	Thickness: 12mm
Origin	CHINA

Product Description

stainless steel roll

1.Product Description
Hot rolled Cold Rolled ASTM 304 4' x 8' stainless steel sheets ,                                                304 4'x8' stainless steel sheets

Description

Inox steel plate,inox steel sheet,stainless steel sheet,stainless steel plate,cold rolled/hot rolledstainless steel sheet,ASTM stainless steel plate,stainless steel,plate

Standard

ASTM A240,JIS G4304, G4305,GB/T 4237,GB/T 8165,BS 1449,DIN17460,DIN 17441

Material

201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H,409,409L, 410,420,430,904L

Model No.

304,0Cr18Ni9,EN1.4301,SUS304,TP304

Surface

No.1, No.4,2D,No.8,2B,BA,No.3,Hair line,Brushed,checkered,sand blast,checkered,embossed, mirror,8k,bright,etc

Exported to

USA,Germany,India,Iran,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,Russia,Chile,Brazil,Argentina, Indonesia,Korea,and so on

Thickness

Form 0.1mm to 150mm

Width

1000mm,1219mm(4feet),1500mm,if you need,we can cut as your required.

Length

2000mm,2440mm(8feet),6000mm,or cut as your required.

Payment terms

T/T ,L/C, Western Union

Price terms

Ex-work,FOB,CIF,CFR,CNF

Application

Plate apply to construction field,shipbuilding industry,petroleum&chemical industry,war and electricity industries,food processing and medical industry,boiler heatexchanger,machinery and hardware fields.

Also can be made according to the customer's required.

Package

Standard export seaworthy packing:

1. bundle package 2. wooden case,wooden pallet package ntainer or bulk

4. special according to customer request

Delivery Time

1.The products in stock will delivery immediately received the payment.

2.According to the order quantity,promopt delivery.

Quality control

Mill Test Certification is supplied with shipment,Third Part Inspection is acceptable.

Container Size

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)      24-26CBM

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)        54CBM

40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)        68CBM

Contact

If you have any needs,pls feel free to contact me.

Finishings of Stainless Steel Sheets

No.03	Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001.	Kitchen utensils,Building, construction
No.04	Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001.	Kitchen utensils, Building construction, Medical equipment.
HL	Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size	Building Construction.
Mirror No.08	Shinning like a mirror	Builiding Construction

Introduction
INCOLOY alloys belong to the category of super-austenitic stainless steel alloys. Nickel, chromium and iron are the principal constituents of this alloy. By adding different additives this alloy can be made to resist different chemical reagents. Good strength and resistance to corrosion are characteristics of these alloys.
Additives such as molybdenum and nitrogen are added to the alloy in order to increase its resistance to pitting, crevice corrosion and thermal stability. The nickel and chromium content extend the corrosion resistance of this alloy over a wide range of environments like non-oxidizing acids, aqueous, caustic chlorides, halides and pulp-mill bleaches. This alloy is available in the form of bars, billets, sheets, round, plate, strips and wire.
This datasheet will look into the chemical composition, properties and applications of INCOLOY 25-6MO.

Chemical Composition
The chemical composition of INCOLOY alloy 25-6MO is given in the following table.ElementContent (%)


Iron, Fe	47.3
Nickel, Ni	24-26
Chromium, Cr	19-21
Molybdenum, Mo	6-7
Manganese, Mn	≤2
Others	Remainder

Physical Properties
The following table discusses the physical properties of INCOLOY alloy 25-6MO.PropertiesMetricImperial


Density	8.03 gm/cm3	0.290 lb/in3

Mechanical Properties
The mechanical properties of INCOLOY alloy 25-6MO are tabulated below.PropertiesMetricImperial


Tensile strength(annealed)	689 MPa	100 ksi
Yield strength(annealed)	331 MPa	48 ksi
Elongation at Break( in 2 in 50 mm)	≥42%	≥42%
Hardness, Rockwell B	86	86
Modulus of Elasticity	188 GPa	27300 ksi
Poissons Ratio	0.33	0.33

Other Designations
Some of the designations used to denote INCOLOY alloy 25-6MO are listed below:-
UNS N08926
Fabrication
Machinability
Machining characteristics of this INCOLOY alloy 25-6MO is similar to that of other austenitic alloys.
Machining of INCOLOY alloy 25-6MO should be done at a slightly lower speed when compared stainless steel using rigid tooling and optimum lubrication and cooling.
Welding
INCOLOY alloy 25-6MO can be welded by gas metal arc welding, gas tungsten arc welding, shielded arc welding, plasma arc welding and submerged metal arc welding. The filler metal and electrodes are usually made of INCONEL alloy.
Hot working
INCOLOY alloy 25-6MO can be hot worked at temperature ranges of 980-1150°C (1800-2100°F).
Cold Working
Cold rolling may be done on the alloy after annealing.
Annealing
INCOLOY alloy 25-6MO should be annealed at temperatures greater than 1175°C (2150°F).
Applications
The INCOLOY alloy 25-6MO is used in the following applications:
Chemical and food processing
Paper bleaching plants
Marine and offshore platform equipment
Air pollution control systems
Salt plant evaporators
Condenser tubes, service water pipes and feed water heaters.

2. Our Service For You
Pre-sale Service
1. Sample can be offered with sample charge and courier fee by buyer's side.
2. We have full stock,and can deliver within short time.Many styles for your choices.
3. OEM and ODM order are accepted, Any kind of logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you
5. All of our products are produce by our professional workman and we have our high-work-effect foreign trade team,you can totally believe our service.

Stock

Form	Specification	Supply Form	Others
Sheet	Thickness:0.40-4.75mm,General Width:1000,1219,1500mm	Whole Coil or piece of it	Cold Annealed,Surface 2B,2E
Plate	Thickness:4.76-60mm,Width:1500,2000,2500mm,Length:3000,6000,8000,8500mm(Under 10mm plate can be coiled)	Whole Coil or piece of it	Single hot rolling,Solid solution annealed state,Surface 1D
Belt	Thickness:0.10-3.0mm,Width:50-500mm	Whole Coil or Specified size	Cold Annealed,Surface 2B,2E
Bar & Rod	Rolled barΦ5-45mm,Length≤1500mm	Polished Bar(circle,Square)	Solution annealing,descaling
Bar & Rod	Forged barΦ26-245mm,Length≤4000mm	Polished Bar(circle,Square)	Solution annealing,descaling
Weld tube	Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm	Base on your requirement	Use for PHE
Seamless Tube	Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm	Base on your requirement	Use for PHE
Wire	Outer diameterΦ0.1-13mm	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
Forged piece	roundness and square alloy	Base on your requirement	Steel, Alloy
Flangs	All kinds of Flangs	Base on your requirement	Steel, Alloy
Welding Material	Coil wire Φ0.90mm/1.2mm/1.6mm	Base on your requirement	Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France.
	Straight WireΦ1.2mm/1.6mm/2.4mm/3.2mm/4.0mm
	Welding rodΦ2.4mm/3.2mm/4.0mm
Tube	Elbow, three links, four links, different diameter size	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
Explosive bonded laminate	Raw Sheet Thickness≥2mm	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
