Home > Products > Fire Truck Mobile Lighting > YZH1.72-5.1CA Mobile Outdoor Electric Industrial Inflatable LED Balloon Light Tower Lamp for Construction Fire Truck Rescu
YZH1.72-5.1CA Mobile Outdoor Electric Industrial Inflatable LED Balloon Light Tower Lamp for Construction Fire Truck Rescu
- 10000 Set / Sets per Month
- China
- T/T L/C
- 7 days
You May Like
Product Details
Material | Aluminum | Usage | Fire Lights, Traffic lights | |
Color Temperature | Pure White | Installation | Wall-hanging | |
Emitting Color | White | Specification | YZH1.72-5.1CA | |
Trademark | Hesheng Safety |
Product Description
Mobile Outdoor Electric Industrial Inflatable LED Balloon Light Tower Lamp for Construction Fire Truck Rescu1. Overview
This mobile outdoor electric industrial inflatable LED balloon light tower lamp is a revolutionary lighting solution designed specifically for demanding environments such as construction sites and fire truck rescue operations. It combines portability, high - intensity illumination, and durability to meet the diverse lighting needs in these challenging scenarios.
Technical indicators:
The YZH1.72-5.1CA fire mobile lighting device adopts high brightness and high-power LED light source, which is energy-saving and environmentally friendly
Features such as high brightness, strong penetration, long service life, and wide irradiation range. It has functions such as automatic reset, making it easy to operate and use
It can be installed on cars or fixed objects. Can be widely used for various nighttime operations such as fire rescue lighting, engineering repairs, and disaster relief
Emergency lighting for rescue and police scene. Suitable for working around the clock.
Main technical parameters:
Product execution standard: GB26755-2011, "Fire Mobile Lighting Devices"
Main light: 4 × 430w LED luminous flux: 45500Lm/piece, total luminous flux: 182000Lm
◆ Illumination: 35 degree angle¬ less than 6 Lx at a distance of 50 meters
Main light service life: over 30000 hours
Main light working voltage: AC220V
Working voltage of gimbal: DC12V or 24V
◆ Pan tilt rotation angle: 360 ° horizontal, 360 ° tilt
◆ Working form of pan tilt: The main light can tilt left and right simultaneously or control the tilt separately (optional).
◆ Lifting mast: Pneumatic lifting, with a height above 7.35 meters above the ground, the internal wiring of the mast body
◆ Working pressure of lifting mast: 2.5Kg/cm 2 ◆ Input voltage of control box: AC220V or AC380V optional.
Control box output voltage: AC220V or AC380V optional.
Operation mode: Control box panel buttons, wired controller, 50 meter wireless remote control.
◆ One click "automatic" reset, intelligent pan tilt protection.
The product has passed the testing of the National Fire Equipment Quality Supervision and Inspection Center
2. Design and Construction
Inflatable Structure: The lamp features an inflatable balloon design. This design not only makes it extremely lightweight but also easy to transport and set up. When not in use, it can be deflated and stored in a compact space, taking up minimal room. The inflatable material is strong and resistant to minor abrasions, ensuring long - term use even in rough conditions.
Mobile Base: It comes with a mobile base that allows for easy movement around the site. The base is equipped with sturdy wheels that can handle different terrains, including uneven ground on construction sites and emergency rescue areas. This mobility enables users to quickly reposition the light tower wherever illumination is needed.
3. Lighting Performance
LED Technology: The light tower is powered by high - quality LED bulbs. These LEDs offer several advantages over traditional lighting sources. They are energy - efficient, consuming less power while providing bright and consistent illumination. The LED bulbs also have a long lifespan, reducing the need for frequent bulb replacements.
High - Intensity Illumination: With its advanced LED configuration, this light tower can emit a powerful beam of light over a large area. The light is evenly distributed, eliminating dark spots and ensuring that the entire work area is well - lit. Whether it's a large construction site or an area where fire truck rescue is taking place, this lamp can provide the necessary visibility for workers and rescue teams.
Color Temperature: The emitting color of the light is white, with a pure white color temperature. This color temperature is ideal for these types of applications as it closely resembles natural daylight. It enhances visibility and makes it easier for workers to distinguish objects and perform their tasks accurately.
4. Electrical and Safety Features
Electric Power: It is an electric - powered light tower, which means it can be connected to a reliable power source. This ensures continuous operation without the need for fuel refills like some traditional lighting towers. The electrical components are well - insulated and protected to prevent electrical hazards.
Safety Design: The light tower is designed with safety in mind. It has built - in protection mechanisms such as over - current protection and short - circuit protection. These features safeguard the equipment from damage and also protect the users from potential electrical accidents.
5. Application Scenarios
Construction Sites: On construction sites, this light tower is invaluable. It can provide illumination during night - time construction work, allowing workers to continue their tasks safely and efficiently. The mobility of the light tower means it can be moved as the construction progresses, ensuring that all areas of the site are well - lit at all times.
Fire Truck Rescue Operations: In fire truck rescue scenarios, visibility is crucial. This light tower can be quickly deployed to the scene to provide bright light, helping firefighters and rescue teams to locate victims, assess the situation, and carry out their rescue operations effectively. It can also be used to illuminate the area around the fire truck for better access and safety.
6. Material and Durability
The main material used in the construction of this light tower is aluminum. Aluminum is a lightweight yet strong material that offers excellent corrosion resistance. This makes the light tower suitable for outdoor use in various weather conditions. The aluminum components are also easy to maintain, requiring only basic cleaning to keep them in good condition.
In conclusion, this mobile outdoor electric industrial inflatable LED balloon light tower lamp is a top - notch lighting solution for construction and fire truck rescue applications. Its innovative design, high - performance lighting, and robust construction make it a reliable choice for professionals in these fields.
