F-81661.T8AR Multi-stage Cylindrical Roller Thrust Bearing

Hot Selling F-81661.T8AR Multi-Stage Cylindrical Roller Thrust Bearings information:

The inner diameter:120mm

The outer diameter:360mm

The width:920mm

Inner inch:4.724inch

Outer inch:14.173inch

Width inch:36.220inch

weight:467kg

Rows No.:8 rows

Basic dynamic load rating Cr:12100kN

Basic static load rating Cor:62400kN

Key Terminology Breakdown:

1.Thrust Cylindrical Roller Bearing

2.Unidirectional Heavy Axial Loads

3.Cylindrical Rollers

4.High Rigidity

 5.Exceptional Load-Bearing Capacity

 6.Low-Friction Characteristics

7.Low-Speed, Heavy-Load Operating Conditions

8.Large Vertical Water Pumps

9.Gearboxes

10.Crane Slewing Rings

Advantages of Crossed Roller Thrust Bearings

1.High Rigidity and Precision

2.Compact and Space-Saving

3.High Load Capacity

4.Resistance to Overturning Moments

5.Simplified Installation and Maintenance

6.High Running Accuracy & Low Runout

Typical Applications

1. Semiconductor manufacturing equipment

2. Industrial robot joints

3. Machine tool rotary tables

4. Medical scanners

5. Astronomical instruments

If you interesting this type,please contact us freely.
