Emerson KJ1501X1-BK1 DeltaV Automation System Power Module

Emerson  KJ1501X1-BK1  DeltaV Automation System Power Module

• Multiple Voltage Outputs: It can convert the input 24V DC power into 12V DC and 5V DC power required by the system, meeting the voltage needs of different devices in the DeltaV system.

• Power Redundancy: This module can form a redundant power supply system with other modules of the same type. When the main power module fails, the standby power module can immediately take over the power supply task to ensure the uninterrupted operation of the system and improve system reliability.

• Overcurrent Protection: It has an overcurrent protection function. When the output current exceeds the set value, the module will automatically cut off the power supply to prevent equipment damage caused by overcurrent, thus protecting other components in the system.

• Wide Temperature Operation: The operating temperature range is usually -40℃ to +60℃, which can adapt to various industrial environments and work stably under extreme temperature conditions.

• High Efficiency and Reliability: It uses industrial-grade components, with high conversion efficiency, which can reduce energy loss. Meanwhile, it has high reliability, which can extend the service life of the equipment.

• Easy Installation: It adopts DIN rail mounting, and the modular design makes it easy to install and maintain, and can be conveniently integrated into existing automation systems.

Working Principle: It is based on power electronics technology and control circuit technology, with the core being switching power devices and control circuits. The switching devices usually adopt semiconductor devices such as MOSFET, BJT, and IGBT. When the switching devices are turned on, they convert the input 24V DC electric energy into 12V DC and 5V DC output electric energy. The comparator in the control circuit compares the feedback information with the set value to control the magnitude and stability of the output voltage. The feedback circuit monitors the changes in the output voltage and sends the feedback signal back to the comparator, enabling the power module to adjust the output electric energy in a timely manner. At the same time, the circuit protection part will detect and protect key components of the power module, such as switching devices, capacitors, inductors, etc., to ensure the normal operation of the module.

• Chemical Industry: The chemical production process is complex, involving many equipment such as reactors, pumps, and valves. KJ1501X1-BK1 can supply power to controllers, I/O cards, etc. in the DeltaV system, ensuring that the system accurately collects parameters such as temperature and pressure of the reactor, and precisely controls the opening and closing of valves and the start and stop of pumps, so as to ensure the safe and stable progress of the production process. Meanwhile, in the face of harsh environments such as corrosive gases and dust in chemical production, this power module can ensure the long-term stable operation of the system with its stable performance and reliable design.

• Petroleum and Natural Gas Industry: At oil and gas extraction sites, there are a large number of sensors used to monitor parameters such as wellhead pressure and flow, and many actuators used to control wellhead switches, etc. In the oil and gas transportation link, it is also necessary to monitor and control pipeline pressure and flow in real time. The KJ1501X1-BK1 power module supplies power to the relevant equipment of the DeltaV system, ensuring that it can work stably in complex field environments (such as high temperature, low temperature, high humidity, etc.), and realizing effective monitoring of the oil and gas production and transportation process.

•


• Power Industry: In power plants, both the operation control of generator sets and the automatic control of auxiliary systems (such as water treatment systems, coal conveying systems) rely on the DeltaV system. This power module provides stable power for the system, ensuring its real-time monitoring of parameters such as voltage, current, and temperature of the generator, as well as precise control of various auxiliary machines. In substations, it can be used to supply power to the DeltaV system, enabling it to reliably collect analog and switching signals in the substation, realize automatic monitoring of substation equipment, and ensure reliable power transmission.

• Metallurgical Industry: The metallurgical production process includes multiple links such as mining, mineral processing, smelting, and rolling, and each link has a large number of equipment that need automatic control. KJ1501X1-BK1 can supply power to the DeltaV system, enabling it to monitor the temperature and pressure of the blast furnace in real time, control the feeding system of the steelmaking furnace, and adjust the speed of the rolling production line, etc., ensuring the continuity of the metallurgical production process and product quality, and improving production efficiency.

•


• Food and Beverage Industry: There are various equipment such as filling machines, packaging machines, and conveyor belts on the food and beverage production line. This power module supplies power to the DeltaV system, enabling it to precisely control the filling volume of the filling machine, the running speed of the packaging machine, and monitor the running status of the conveyor belt, etc. At the same time, it ensures that the system can collect signals such as temperature and humidity from environmental monitoring equipment in real time, guaranteeing product quality and production efficiency, and meeting the strict requirements of the food and beverage industry for hygiene and production accuracy.

• Aerospace Field: The aerospace field has extremely high requirements for the reliability and stability of equipment. In scenarios such as aerospace ground test equipment and aerospace vehicle simulation control systems, the DeltaV system can be used to precisely control and monitor relevant parameters. The KJ1501X1-BK1 power module provides stable power for it, ensuring that the system runs reliably in high-demand environments and supporting the smooth progress of aerospace missions.
