Home > Products > hydraulic cylinder > Hydraulic Outrigger Cylinder For Boom Crane Leg Cylinder
Hydraulic Outrigger Cylinder For Boom Crane Leg Cylinder
≥1 Pieces
- shanghai
- T/T L/C PayPal D/P Western Union Other
- 30 days
You May Like
-
The Hydraulic Cylinder of the Truck Crane Tilts and Shifts Laterally, Rotates Left and Right, and Dislocates the Oil Seal.
-
Hydraulic Cylinder for Bidirectional Lifting, Small-sized 40mm, Custom-made, Single-directional Oil Cylinder With 2-ton Pressure, Ear Ring Type,
-
Lift Hydraulic Cylinder for Steel Coil Flatbed Truck
-
Customized Power Steering Cylinder Shaft
-
Stomized Rear Hydraulic Jack Legs Hydraulic Cylinder With Adjustable Latch System
-
Customized Hydraulic Cylinder for Front Outrigger Lift Engineering Hydraulic Cylinders, Excavator Hydraulic Cylinders and Forklift
Product Details
| Material | Cast Iron | Certification | GS, ROHS, CE, ISO9001 | |
| Structure | Piston Type | Work Temperature | Normal Temperature | |
| Adjusted Form | Regulated Type | Acting Way | Double Acting | |
| Working Method | Straight Trip | Pressure | Medium Pressure | |
| Transport Package | Wooden box | Specification | 280/200-300 | |
| Trademark | hongda | Origin | china |
Product Description
| Product title | Lateral Hydraulic Cylinder |
| Product Description | A lateral hydraulic cylinder serves a pivotal role in various mechanical systems by providing controlled side-to-side movement. This specialized hydraulic component converts hydraulic fluid pressure into linear force, enabling precise and efficient lateral motion within a mechanical setup. |
| Product Name | Hydraulic Cylinder |
| Brand | HongDa Hydraulics |
| Model Number | W140-63/35-450 |
| Weight | 20Kg |
| Dimension | 700X115X115 |
| Core Component | piston rod, cylinder barrel, end cap |
| Applicable Industries | General Equipment Hydraulic Cylinder |
| Bore Dia | 63 mm/5 in |
| Rod Dia | 35 mm/3.543 in |
| Stroke | 450 mm/39 in |
| Operating Temperature | -20°~50° |
| Maximum Working Pressure | 14Mpa |
| Mounting Style | earrings |
| Paint | customization acceptable |
| Working Medium | hydraulic oil |
| Certification |
Commonly used in industrial applications such as manufacturing machinery, material handling systems, and agricultural equipment, the lateral hydraulic cylinder allows for accurate positioning, pushing, or pulling actions. Its design, incorporating a durable cylinder, piston, and rod, ensures robust performance, while integration into hydraulic systems facilitates the controlled application of pressure, allowing for versatile and precise lateral movements. Regular maintenance is essential to uphold the cylinder's reliability, making it a fundamental component in systems that require controlled horizontal motion.
