Home > Products > ABB > ABB CI869K01 3BSE049110R1 Communication Interface

ABB CI869K01 3BSE049110R1 Communication Interface

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T PayPal Western Union

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other, Global universal model	Condition	Other, Global universal model
Task	Other, Global universal model	Mathematical Model	Other, Global universal model
Signal	Other, Global universal model	Customized	Non-Customized
Structure	Other, Global universal model	Operating Temperature	-40℃~+70℃
Dimensions	100mm×160mm×80mm	Input voltage	24VDC

Product Description

Overview

ABB CI869K01 (order number 3BSE049110R1) is a high-performance industrial communication interface module belonging to the I/O module family of the AC 800M control system. It is mainly used to realize high-speed data interaction between the control system and on-site equipment or other automation systems. As a "data gateway" in the industrial automation architecture, it supports multiple mainstream industrial communication protocols and can seamlessly connect devices of different brands and types (such as PLCs, DCSs, sensors, actuators, etc.), solving the "protocol island" problem in industrial scenarios. Meanwhile, it features high reliability, anti-interference capability, and flexible expandability, making it suitable for industrial environments with strict requirements on communication stability, such as electric power, chemical industry, metallurgy, and manufacturing.

Technical Parameters

Category	Specific Parameters
Power Supply	Input voltage: 24VDC (allowable fluctuation range ±20%); Rated power consumption: ≤15W
Communication Interfaces	- 2 Gigabit Ethernet ports (supporting redundant configuration) - Compliant with IEEE 802.3 standard, with adaptive transmission rate of 10/100/1000 Mbps
Protocol Support	Compatible with mainstream industrial Ethernet protocols such as Profinet IO (IRT real-time communication), Modbus TCP/IP, and EtherNet/IP
Real-time Performance	Deterministic communication cycle: minimum 1ms; End-to-end communication delay ≤50μs (in Profinet IRT mode)
Environmental Adaptability	Operating temperature: -40℃~+70℃; Relative humidity: 5%~95% (non-condensing); Protection class: IP20 (must be installed in a control cabinet)
Electrical Isolation	Isolation voltage between communication interface and backplane bus ≥2500VAC; Isolation between power supply and signal ≥1500VAC
Mechanical Specifications	Dimensions: 100mm×160mm×80mm (length × width × height); Installation method: DIN rail or panel mounting
Reliability Indicators	Mean Time Between Failures (MTBF) ≥300,000 hours; Supports hot swapping, no need to shut down the system when replacing the module

Functional Features

High-speed Real-time Communication Capability
Based on a Gigabit Ethernet architecture, it supports Profinet IRT (Isochronous Real-Time) mode, enabling microsecond-level deterministic data transmission. This ensures the synchronization of equipment collaboration in time-sensitive scenarios such as motion control and precision machining (e.g., multi-axis linkage control of robots in production lines).
Protocol Conversion and Compatibility
Equipped with a built-in protocol conversion engine, it can realize seamless conversion between different industrial bus protocols (such as Profinet and Modbus TCP) without the need for additional gateways. This simplifies the complexity of hybrid networking with multi-brand devices and reduces system integration costs.
Redundant Design and High Availability

Supports dual Ethernet port redundancy. In case of a primary link failure, it can automatically switch to the backup link within 5ms to ensure uninterrupted communication;
Compatible with the power redundancy and CPU redundancy architecture of the AC 800M system, enhancing the fault resistance of the entire control system.

Online Diagnosis and Maintenance
The operating status of the module (such as communication traffic, link quality, temperature, etc.) can be monitored in real-time through ABB Control Builder M software. It supports automatic reporting of fault codes and remote diagnosis. With hot-swappable design, maintenance can be performed without stopping the system, reducing downtime.
Anti-interference and Industrial-grade Stability
Adopts an enhanced electromagnetic compatibility (EMC) design and has passed the IEC 61000-6-2 anti-interference certification for industrial environments, capable of resisting strong electromagnetic interference on-site (such as interference from motor startup and inverter operation). The housing is made of anti-corrosion metal material, adapting to harsh environments such as dust and humidity.

Application Fields

Industrial Automation Production Lines: Used to connect PLCs, robots, sensors, and other equipment to achieve high-speed data interaction and collaborative control (e.g., automobile welding production lines, electronic component assembly lines).
Process Control Field: In DCS systems of chemical, petroleum, natural gas and other industries, it serves as a communication bridge between on-site equipment and control units, transmitting key process parameters such as pressure, flow, and temperature.
Energy and Power Industry: Suitable for scenarios such as substation automation and wind farm equipment monitoring, ensuring reliable transmission of real-time data collection and remote control commands.
Transportation Infrastructure: Such as metro signal systems and port machinery control, supporting the safe and efficient operation of equipment through highly stable communication.
