EU General Monel 400 N04400 Na12 Nu30 Nickel Alloy Bar Rod

FOB Price

Negotiable / Ton

1 Ton(Min.Order)

Supply Ability 0 Ton / Tons per Month
Payment TermsT/T
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Seamless	Technique	Cold Rolled
Surface Treatment	Other	Material	Stainless steel
Section Shape	Round

Product Description

Basic Info.

Model NO.

Monel 400, 2.4360, UNS N04400

Purity

63%

Alloy

Type

Nickel Bar

Powder

Not Powder

Diameter

3-300mm

Surface

Black, Bright, Polished, Pickling

Length

as Your Requirments

MOQ

100kgs

Sample

Free-Sample

Condition

Annealed;Heat Treatment;

Technique

Cold Rolled, Hot Rolled

Mtc

Cold Drawn Hot Rolled,Forged

Stock

in Stock

T.S

517

Key Words

Monel 400 Round Bar

Transport Package

Wooden Package

Specification

Monel 400

Trademark

ZYTC

Origin

China

HS Code

7502200000

Production Capacity

50000kg/Month

Product Description

BS AMS Standard Monel 400 Nickel Based Alloy Bar for Frames for eyeglasses

Material	Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape	Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
Grade	Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
	Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
	Alloy : Alloy 20/28/31
	Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
	Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
	Haynes: Haynes 230/556/188
	Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
	Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816
	Incoloy: Incoloy 800/800H/800HT/825/925/926;
	GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
	Monel: Monel 400/K500/R405
	Nitronic: Nitronic 40/50/60;
	Nimonic: Nimonic 75/80A/90/A263 ;
Specification	Wire: 0.01-10mm Strip: 0.055.0-5.0250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product Characteristics	1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Standard	GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Inspection	ISO,SGS,BV and so on.
Application	High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines
Packaging	1. cases packed in wooden cases 2. paper packaging 3. plastic packing 4. foam packaging Packaging according to customer requirements or products
Delivery	7-25days orAccording to the product
Payment	L/C,D/A,D/P,T/T,Western Union,MoneyGram,According to customer requirements payments for offline orders.

Introduction

MONEL nickel alloy is a solid solution alloy that can be hardened by the process of cold working.

MONEL is a trademark of Special Metals Corporation under which a series of nickel-copper alloys are grouped. Commercially there are many types of MONEL available, such as alloy 400, alloy 401, alloy R-405, Alloy K-500 and Monel 404.

The Monel 400 alloy is also known as super alloy monel. This alloy is available in some standard shapes such as hexagon, round, tube, pipe, plate, strip, sheet and wire.

The proportions of copper and nickel used to make monel are the same as that found in the nickel ore found in Ontario mines. This alloy exhibits good corrosion resistance. This datasheet will look into the chemical composition, properties and applications of MONEL 400 alloy.

Chemical Composition

The chemical composition of MONEL 400 alloy is given in the following table.

Element	Content (%)
Nickel, Ni	Remainder
Copper, Cu	28-34
Iron, Fe	2.5 max
Manganese, Mn	2 max
Silicon, Si	0.5 max
Carbon, C	0.3 max
Sulphur, S	0.024

Physical Properties

The following table discusses the physical properties of MONEL 400 alloy.

Properties	Metric	Imperial
Density	8.8 gm/cm3	0.318 lb/in3

Mechanical Properties

The mechanical properties of MONEL 400 alloy are tabulated below.

Properties	Metric	Imperial
Tensile strength(annealed)	517-620 MPa	75-90 ksi
Yield strength	172-345 MPa	25-50 ksi
Modulus of elasticity	179 GPa	26000 ksi
Poisson's ratio	0.32	0.32

Some of the other designations that are used to denote MONEL 400 alloy are as below:

AMS 4574
AMS 4675
AMS 4731
ASTM B163
ASTM B165
ASTM F96
UNS N04400
FabricationMachinability
The machinability of MONEL 400 is difficult as it work-hardens during machining. The conventional machining techniques used on iron alloys may be used for this alloy.
Welding
Welding methods including gas-arc welding, metal-arc welding, gas-metal-arc welding and submerged-arc welding are recommended on this alloy.
Forging
Forging of this alloy is to be done by controlled procedures.
Hot working
Hot working on this alloy needs to be done by choosing proper temperatures. Typical temperatures for hot working range between 648-1176°C (1200-2150°F).
Cold working
Cold working may be done using soft die materials for better finishing.
Annealing
MONEL 400 alloy may be annealed at 926°C (1700°F).
Applications
The MONEL 400 alloy is used in the following applications:-

Marine fixtures, pumps, valves and piping systems for sea water applications
Chemical plant equipment
Frames for eyeglasses
Aerospace applications
Musical instruments.
