Product Details
| Certification | ISO | Warranty | 18 months | |
| Application | Sewerage Treatment, Food, Chemical | After-sales Service | Lifetime service | |
| Performance | Explosion | Screw Number | Double Screw Pump | |
| Screw Suction Method | Single Suction | Pump Shaft Position | Horizontal | |
| Transported materials | Crude oil, residual oil | Export pressure | 1.0Mpa | |
| Rated flow rate | 60m3/h | Power of the motor | 45KW-4 | |
| pump body | 20# | spiral casing | 38CrMoAl | |
| axle | 42CrMo | bearing | SKF/NSK | |
| Gear pair | 20CrMnTi | mechanical seal | single mechanical seal | |
| Transport Package | Packaging for sea freight | Specification | 2Ga156-60W | |
| Trademark | WGS | Origin | HUANG SHAN |
Product Description
Advantages:
? ? Long Service Life
?Low Noise And Vibration
? High Efficiency
?Smooth Operation
? Easy Dismounting
?Easy Maintenance, Low Cost
? Short Flow Path
?Pumped Media Can Contain Particles
Medium:
Slurry, adhesive, grease, dairy products
Application:
W2G series WGS screw pump is twin-screw, single-volute, short-flow-path, self-priming positive displacement pump. Flow is regulated with low speed and frequency control, while the short flow path prevents material coalescence and clogging.
Partial Service:
A Turkey Chemical Company, W2G140-36W, 10m3 /h, 1.0Mpa, 280°C, transfer for PET poltmer
A ShanXi Chemistry Company, W2GRT208-40W, 50m3 h, 1.5Mpa, 420°C, transfer for coal tar
An Inner Mongolia Coal Chemical Company, W2GRT208- 40W, 50m3 /h, 1.5Mpa, 420°C, transfer for coal tar
A Lanzhou Heavy Equipment Company, W2Gs208-72W, 200m3 /h, 1.8Mpa, 200°C, transfer for bitumen
A Hunan Petrochemical Company, W2Gs182-48W, 165m3 / h, 1.0Mpa, 280°C, transfer for used oil
