Home > Products > Hygienic grade piping series > EU General Factory Direct Sales G30 Ns3404 N06030 2.4603 Hastelloy Plate Apply for Heat Exchange

EU General Factory Direct Sales G30 Ns3404 N06030 2.4603 Hastelloy Plate Apply for Heat Exchange

FOB Price

Negotiable / Ton

1 Ton(Min.Order)

Supply Ability 0 Ton / Tons per Month
Payment TermsT/T
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Seamless	Technique	Cold Rolled
Surface Treatment	Other	Material	Stainless steel
Section Shape	Round

Product Description

Basic Info.

Model NO.

MD-52

Certification

ISO

Surface Treatment

Coated

Technique

Cold Rolled

Application

Ship Plate, Boiler Plate, Container Plate

Special Use

Measuring Tools, Cutters in Common Steel, High-strength Steel Plate

Stock

Width

10mm~3500mm

Length

2m, 3m, 6m, 8m, 12m, or as Required.

Surface

Varnished, PE Coated, Galvanized.

MOQ

1000kgs

Price Term

Ex-Work, Fob, CIF, CFR, etc.

Delivery Time

Prompt Delivery, or as Order′s Quantity.

Transport Package

Standard Export Seaworthy

Specification

Thickness: 0.3mm~500mm

Trademark

KINGMETAL

Origin

China

Production Capacity

300 Ton//Month

Product Description

Hastelloy G30 Sheet, Hastelloy G30 Coil Suppliers, Hastelloy G30 Shim Stock
Hastelloy G30 Sheet, Plate & Coils Specifications

Sizes	1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness	0.1mm to 100 mm Thk
Width	10-2500mm
Length	2m, 2.44m, 3m, or as required
ASTM	ASTM B168
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Stock in form of	Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate
Material	JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW6002, etc DIN:H-Ni99.96, H-Ni99.95, H-Ni99.92, H-Ni99.90, H-Ni99.5, H-Ni99, etc
ASTM Standard	ASTM A162, GB/T2054, DIN177502002, ASTM B127,ASTM B435, ASTM B582, ASTM B575, ASTM B168, ASTM B443, ASTM B463, ASTM B626, ASTM B536, etc
Why choose Kingmetal Steel Overseas	EN 10204/3.1B, Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc High special strength, high melt point Excellent corrosive resistance,good thermal resistance Customer support after-sales service Huge Stock, Timely delivery Strict Control from Raw Material to Finished Inconel 600 Plate Free Quote, Inquiry answered within 24 hours
Inconel 600 profiling	To provide a full profiling service we use numerous profiling methods including: Laser Plate Cutting Plasma Plate Cutting Oxy-propane Flame Cutting

Hastelloy G30 Plate, Sheet & Coil Chemical Composition

%	Ni	Cr	Mo	Fe	Co	W	C	Mn	Si	P	S	Al	Cu	V
min	balance	32.25	7.6
max	balance	34.25	9.0	2.0	1.00	0.60	0.050	0.50	0.60	0.030	0.015	0.40	0.30	0.20

Alloy G30 Sheets, Plates & Coils Mechanical & Physical Properties

Density	Thermal Conductivity	Specific Heat	Melting Range
g/cm3	W/m.k	J/kg. k	°C
8.22	10	450	1332-1361

Hastelloy G30 Plate, Sheet & Coil Chemical Composition

Element	Content (%)
Nickel, Ni	43
Chromium, Cr	28.0-31.5
Iron, Fe	13-17
Cobalt, Co	5
Molybdenum, Mo	4-6
Tungsten, W	1.50 - 4
Manganese, Mn	1.50
Copper, Cu	1 - 2 .40
Silicon, Si	0.8
Phosphorous, P	0.040
Carbon, C	0.030
Sulfur, S	0.020

Hastelloy Alloy G30 Sheets, Plates & Coils Mechanical Properties

Properties	Metric	Imperial
Density	8.22 g/cm3	0.297 lb/in3
Melting point	1371oC	2500oF

Hastelloy G-30/ Hastelloy G-35 Sheet, Plate & Coil equivalent grades

Grade	UNS	Werkstoff Nr.
Hastelloy G-30	DIN 2.4603	UNS N06030
Hastelloy G-35	DIN 2.4643	UNS N06035

Hastelloy G30 Sheets & Plate Dimenisons

Surface finish	Thickness (mm)	Width (mm)
2B - Cold rolled, heat treated, pickled, skin passed	0.25-8.0	max. 2032
2D - Cold rolled, heat treated, pickled	0.4-6.35	max. 1524
2E - Cold rolled, heat treated, mechanically descaled	0.4-8.0	max. 2032
2R - Cold rolled, bright annealed	0.25-3.5	max. 1524
2H - Work hardened	0.4-6.35	max. 1524
Polished, brushed	0.5-4.0	max. 1524
