EU General Astmb622 Hastelloy C22 /Uns N06022/ 2.4602 Nickel Based Alloy Nickel Alloy Steel Seamless Tube--Pulp & Paper Industries

FOB Price

Negotiable / Ton

1 Ton(Min.Order)

Supply Ability 0 Ton / Tons per Month
Payment TermsT/T
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Seamless	Technique	Cold Rolled
Surface Treatment	Other	Material	Stainless steel
Section Shape	Round

Product Description

Basic Info.

Model NO.

Sb 622 UNS N06022

Composition

Inconel

Technique

Hot Rolled

Shape

Bar

Surface Treatment

Coated

Special Use

High-strength Steel Plate, Wear Resistant Steel, Cold Heading Steel, Mold Steel

Application

Die Steel Bar

Materials

Nickel Alloy

Outer Diameter

3-219mm

Length

5.8m-12m or as Required

Thickness

0.4 - 12.7mm

Steel Grade

ASTM B622

Transport Package

in Bundles or Wooden Box

Specification

21.3-1219mm

Trademark

JIADE

Origin

China

HS Code

7307930000

Production Capacity

500 Tons

Product Parameters

Model Number	ASTM B622 UNS N06022 Tube.
Brand Name	OEM
origin	China
Small Orders	Accepted

The combination of good weldable properties along with resistance to the grain-boundary precipitate being formed on the enables the Hastelloy C22 Tube to be used in an as welded condition. This being said, however, the Tubing Sb 622 UNS N06022 must not be used beyond a temperature of 1250° F. At temperatures exceeding 1250° F, the Hastelloy UNS N06022 Tubing material is prone to the formation of detrimental phases. This, in turn, could lead to loss of several important properties of the ASTM B622 UNS N06022 Tube.

2.4602 Alloy 22 Exhaust Tubing stock at factory price

As the ASTM B619 UNS N06022 Tube is able to withstand both oxidizing and reducing corrosive compounds, the Alloy C22 Tube proves to be an asset to the chemical processing industry. This is because, in chemical processing industries, the Alloy C22 Seamless Tubing offers optimum resistance to corrosion in upset conditions. The Hastelloy C22 Seamless Tubing proves to be useful against localized corrosion like pitting and crevice corrosion. Apart from marine environments, the 2.4602 Alloy 22 Tube resists acetic anhydride as well. In the presence of oxidizing media such as nitric acid, ferric and cupric salts, the Hastelloy Alloy C22 Tubing demonstrates good resistance. In fact, the C22 Hastelloy Welded Tubing has superior resistance to oxidizing aqueous media. Contact Oshwin to get the quote for Hastelloy C22 Tubing.

ASTM B622 UNS N06022 Tube sizes

C22 Hastelloy Seamless Tubing

Size: 1/2" OD - 12" OD
OD: 3.00 - 219.10 mm
Thickness : 0.40 - 12.70 mm
Length: Single, Double Random & Cut Length

Hastelloy Alloy C22 Welded Tubing

Size: 1/2" - 12" OD, Guage: 25 SWG - 10 SWG
OD: 6.35 to 114.3 mm O.D
Thickness : 0.8 - 12.7 mm
Length: up to 26 Meters

Hastelloy UNS N06022 Tubing SpecificationHastelloy UNS N06022 Annealed Tube & Alloy 22 Welded Tube in various size range

ASTM/ ASME Specification	ASTM B619/ ASME SB 619, ASTM B622 / ASME SB 622 Standard Specification for Seamless & Welded Superheater, Condenser, Hydraulic, Boiler and Heat-Exchanger Tubes
Shapes	Hastelloy UNS N06022 Round, Rectangular, Square, Hydraulic, Straight, "U" Shape, Coiled, Honed Tubes, Pan Cake Coils
Manufacturing Type	Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded
Thickness Range	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS
Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Standard	SUS, JIS, AISI, ASTM, GB, DIN, EN
Delivery Condition	Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, MF
Value Added Services	Cutting Beveling Threading Draw & Expansion as per required Size & Length Ultrasonic Testing Annealed & Pickled Bending Destructive and Non Destructive
END	Plain End, Beveled End, Treaded Hastelloy Alloy C22 Tube
Processing Service	Bending, Welding, Decoiling, Punching, Cutting, Moulding
Technique	C22 Hastelloy Cold drawn, Cold rolled, Hot rolled, Extrusion Tube
Marking	Specification Material Grade Nominal Size Schedule or Wall Thickness Method of Manufacturing (Seamless / Welded) Heat Number Manufacturer's Name or Custom Logo - on request Marked Sample: ASTM B622 UNS N06022 Seamless 113.60 mm OD x 6 mm W.T. HEAT No. xxxxxx
Test Certificate	DFARS compliant EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC) HS Code Commercial Invoice Raw Materials Certificate Moisture testing Fumigation Certificates 100% Radiography Test Report Heat Treatment Charts Third Party Inspection Report Surface roughness measurement Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab Form A for Generalized System of Preferences (GSP)
Alloy NW 6022 Tubing Packaging	Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or Standard seaworthy export packing or as per customers' request
Port	Mumbai, India

Most Selling types of ASME SB 622 UNS N06022 Tubes
ASTM B622 UNS N06022 Seamless Tube

Hastelloy DIN 2.4602 Extruded Seamless Tube
C22 Hastelloy Annealed Tubes
Hastelloy Alloy C22 Seamless Round Tubing
Alloy NW 6022 Redrawn Tube
Hastelloy UNS N06022 Seamless Heat exchanger Tubes
ASTM B622 Alloy C22 Seam Weld Tubing
Hastelloy UNS N06022 Welded Tube

C22 Hastelloy Cold Rolled Tube
Alloy NW 6022 Coiled Tubing
ASME SB 622 UNS N06022 Rectangular Tube
Hastelloy Alloy C22 Square Tubing
ASTM B622 Alloy C22 Exhaust Tubing
Alloy C22 Hastelloy Straight Tube

Hastelloy Alloy C22 Tubes for sale

ASME SB 622 UNS N06022 Exhaust Tubing	ASTM B622 UNS N06022 Dom Tubing
Hastelloy Alloy C22 Rectangular Tubing	Hastelloy UNS N06022 Hydraulic Tubing
C22 Hastelloy Seamless Tubing	ASME SB 622 UNS N06022 Round Tubing
ASTM B622 UNS N06022 Instrument Tubing	ASTM B619 Alloy C22 Sanitary Tube
Hastelloy UNS N06022 Square Tubing	Hastelloy C22 1 inch Tube

C22 Hastelloy Tubing Mechanical Properties

Density	Melting Range	Yield Stress (0.2%Offset)	Tensile Stress	Elongation
8.69 g/cm3	1399 °C (2550 °F)	Psi - 45000 , MPa - 310	Psi - 1,00,000 , MPa - 690	45 %

Alloy NW 6022 Tube Chemical Composition

Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Balance	0.010 maximum	12.5 - 14.5	0.50 maximum	0.08 maximum	2 - 6	0.02 maximum	0.02 maximum	2.5 maximum	20 - 22.5

ASTM B622 Alloy C22 Equivalent

NICKEL ALLOY	UNS	DIN / WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
Hastelloy C22	N06022	2.4602	-	NiCr21Mo14W	NW 6022	-	-

Product Description

Product Name	Nickel alloy steel pipe
Grade	N06022
Standards	JIS, AISI, ASTM, GB, DIN, EN
Diameter	1/8''-36'' 10.3mm-914.4mm
Thickness	1mm-70mm
Length	5000mm-12000mm,or customize
Surface	AP,BA,2B,or others
Pipe Ends	Bevel end,Plain end,Bevel both ends,Bevel large end,Bevel small end,or others

Application	petroleum,foodstuff,chemical industry,construction, electric power,nuclear,energy,machinery,biotechnology,paper making,shipbuilding,boiler fields.
Quality and test	Radiography Test Report,PMI,Heat Treatment Charts,Manufacturer Test Certificate,etc.
Packing	Ply Wooden Boxes,PE Fabric Bundles,Standard seaworthy export packing,Plastic Bags, or as required
Delivery time	20-75 days

Chemical Composition

Grade	Ni	Cr	Mo	W	C	Si	Co	Mn	V	P	S
C22	Bal	20.00-22.50	12.50-14.50	2.50-3.50	≤0.015	≤0.080	≤2.50	≤0.50	≤0.35	≤0.02	≤0.02

Mechanical Properties

Grade	Tensile Strength ksi(MPa )	Yield Strength (MPa)	Elongation (%)
C22	≥100(690)	≥310	≥45

the ASTM B622 Nickel alloy seamless tube and pipe tolerance

Specification	OD(D) SIZE	PERMISSIBLE VARIATION	THICKNESS(S) SIZE	PERMISSIBLE VARIATION	LENGTH(L) SIZE	PERMISSIBLE VARIATION
B622 (For Cold-workedPipe and Tube)	10≤D<16	±0.13		±15%		OD<50.8: +3.2/-0 OD>50.8:+4.8/-0 Details refer to B829
	16≤D<38	±0.19		±10%
	38≤D<76	±0.25
	76≤D≤82	±0.38
B622 (For Hot-finished Tube)	19≤D≤38	+0.4/-0.8		±12.5%
B622 (For Hot-finished Tube)	38.1≤D≤82	+0.8/-0.8		±12.5%
B622 (For Hot-finished Pipe)	25≤D≤48	±0.38		+16%/-12.5%
B622 (For Hot-finished Pipe)	48≤D≤82	±0.51		+16%/-12.5%
