Nickel Alloy Stainless Pipe Hastelloy C 276 N10276 Hastelloy C 22 N06022 Stainless Steel Seamless Pipe for Architectural Decoration Industry

Hastelloy C276 Seamless Pipe size

4 to 219mm W. T.: 0.5 to 20mm

Alloy C276 Seamless Tube Size

3.35 mm OD To 101.6 mm OD

Hastelloy C276 Welded Pipe size

5.0 mm - 1219.2 mm

ASTM B619 N10276 Welded Tube Size

6.35 mm OD To 152 mm OD

UNS N10276 Pipe Schedule

SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60,
SCH80, SCH120, SCH140, SCH160, XXS

Hastelloy Pipe & Tube Form

Round, Square, Hollow, Rectangular, Hydraulic, Straight Pipes or 'U' bent Tubes,
Hollow, LSAW Tubes Etc.

C276 Hastelloy Alloy Pipe & Tube End

Plain End, Beveled End, Treaded.

ASME SB626 Hastelloy C276 Pipe Length

Single Random, Double Random & Cut Length.

Origin

China

Marking

All Hastelloy Pipes & Tubes are marked as follows: Standard, Grade,
OD, Thickness, Length, Heat No. (Or according to the customer's request.)

Hastelloy Pipe Finish

Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF

Material Test Certificates (MTC)

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2

Test

· Chemical Analysis - Spectro Analysis

· Hardness Test

· Intergranular Corrosion (IGC) Test

· Pitting Resistance Test

· Flattening Test

· Flaring Test

· Mechanical Testing Such as Tensile of Area

· Positive Material Identification - PMI Testing

· Micro and MacroTest

Hastelloy pipe Specialized in

Large Diameter Alloy C276 Pipe

Hastelloy alloy C-276 UNS N10276/W.Nr. 2.4819 Standard

ASTM B619, ASTM B622 / ASME SB619, ASME SB622, ASTM B 622/B 829 & ASME SB 622/SB 829 (Seamless Tube),
ASTM B 626/B 751 & ASME SB 626/SB 751 (Welded Tube), ASTM B 619/B 775 & ASME SB 619/SB 775 (Welded Pipe),
ISO 6207 (Seamless Tube), DIN 17751, VdTüV 400/12.98

Swg & Bwg

10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.

Hastelloy C276 tubing wall thickness

0.020" -0.220", (special wall thicknesses available)

Hastelloy C276 Tube Type

Seamless, ERW, EFW, Welded, Fabricated

Application

Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger

Value Added Service

Draw & Expansion as per required Size & Length, Polish (Electro &
Commercial) Annealed & Pickled Bending, Machining Etc.

Specialize in

Hastelloy C276 Capillary Tube & Other Odd Size
Hastelloy C276 Heat Exchanger & Condenser Tubes

Test Certificate

suppliers Test Certificate
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection

Hastelloy C276

2.4819

N10276

NW 0276

-

ХН65МВУ

NiMo16Cr15W

ЭП760

Balance

0.010 max

15.00 - 17.00

1.00 max

0.08 max

4.00 - 7.00

0.04 max

0.03 max

2.5 max

14.50 - 16.50

8.89 g/cm3

1370 °C (2550 °F)

Psi - 1,15,000 , MPa -790

Psi - 52,000 , MPa - 355

40 %

NB Sizes (in stock)

1/8" ~ 8"

SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160

Upto 6 Meters

Hastelloy C276 Seamless Pipe (Custom Sizes)

5.0mm ~ 203.2mm

As per requirement

Upto 6 Meters

Hastelloy C276 Welded Pipe (in Stock + Custom Sizes)

5.0mm ~ 1219.2mm

1.0 ~ 15.0 mm

Upto 6 Meters
