Metal Titanium Plate and Sheet Titanium Alloy Supplier

FOB Price

Negotiable / Ton

100000 Tons(Min.Order)

Supply Ability 0 Ton / Tons per Month
Port TIANJIN
Payment TermsT/T
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other, Titanium Sheets	Shape	Other, Plate
Color	Silver	Transport Package	Wooden Box
Specification	0.3-100mm	Origin	CHINA

Product Description

Titanium and titanium alloy steel

Basic Info.

Model NO.

0.3-100mm

Hot Rolled Thickness

4.1-100

Width

Max3000mm

Length

Customed

Type

Titanium Sheets

Application

Industrial, Medical

Technique

Cold Rolled

Grade

GR2

Transport Package

Wooden Box

Specification

4.1-100

Trademark

Ruiyang

Origin

China

Production Capacity

5000tons/Year

Product Description

Titanium Sheet & Plate Available from 0.3mm to 100mm thick cold roll and hot roll

AVAILABLE SIZES:
Sheet is 0.3mm to 4.1mm thick, up to 1500mm width cold roll
Plate is 4.1 mm to 100mm thick, up to 3000mm width hot roll

PROCESSING
Hot rolling and cold rolling

PROCESSING STANDARD:
ASME SB/B265, AMS 4911, AMS 4919, AMS 4914, ASTM F67, ASTM F136, ASTM F1341, ISO 5832-2, MIL-T-9046

EXAMPLE APPLICATIONS:
Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry etc

STANDARD	CHEMICAL COMPOSITION (weight %, max or range)											MECHANICAL PROPERTIES (min)
ASTM B265	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Tensile	Yield	El.	Red.
ASTM B265	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Mpa	Mpa	%	%
GR 1	R50250	0.03	0.08	0.015	0.2	0.18						240	138	24	30
GR 2	R50400	0.03	0.08	0.015	0.3	0.25						345	275	20	30
GR 3	R50550	0.05	0.08	0.015	0.3	0.35						450	380	18	30
GR 4	R50700	0.05	0.08	0.015	0.5	0.4						550	483	15	25
GR 5	R56400	0.05	0.08	0.015	0.4	0.2	5.5-6.75	3.5-4.5				895	828	10	25
GR 7	R52400	0.03	0.08	0.015	0.3	0.25			0.12-0.25			345	275	20	30
GR 9	R56320	0.03	0.08	0.015	0.25	0.15	2.5-3.5	2.0-3.0				620	483	15	25
GR 12	R53400	0.03	0.08	0.015	0.3	0.25				0.2-0.4	0.6-0.9	483	345	18	25
GR 23	R56401	0.03	0.08	0.0125	0.25	0.13	5.5-6.5	3.5-4.5				828	759	10	15

TITANIUM MATERIALS SUPPLY SCOPE
TITANIUM GRADE	UNS NO.	WIRE	BAR	SHEET	PLATE	TUBE	PIPE	FITTING	FORGING	FASTENER
Ti Grade 1	R50250	√	√	√	√	√	√	X	√	√
Ti Grade 2	R50400	√	√	√	√	√	√	√	√	√
Ti Grade 3	R50550	√	√	√	√	X	X	X	√	√
Ti Grade 4	R50700	√	√	√	√	X	X	X	√	√
Ti Grade 5 (6Al 4V)	R56400	√	√	√	√	X	X	X	√	√
Ti Grade 7 (0.2Pd)	R52400	√	√	√	√	√	√	√	√	√
Ti Grade 9 (3Al 2.5V)	R56320	√	√	√	√	√	X	X	√	√
Ti Grade 11	R52250	√	√	√	√	√	√	X	√	√
Ti Grade 12 (0.3Mo 0.8Ni)	R53400	√	√	√	√	√	√	√	√	√
Ti Grade 17	R52252	X	√	√	√	√	√	X	√	√
Ti Grade 23 (6Al 4V Eli)	R56401	√	√	√	√	X	X	X	√	√
Notes 1) √-Available, X-Unavailable
Notes 2) For other grades like Ti6Al2Sn4Zr2Mo, Ti6Al6V2Sn, Ti8Al1Mo1V, Ti6Al2Sn4Zr6Mo, Ti15V3Cr3Sn3Al, please contact us for details.
Notes 3) It may differs a little for materials in different sizes, please also contact us.

Titanium and Alloy Products

Product name	Specifications
Titanium Rod & Bar & Ingots	Ф3mm~Ф1020mm,the maximum weight is up to 12t
Titanium Slab	(80~400)mm×(~1500)mm×(~2600)mm
Titanium Forgings	Weight per piece≤2000kg
Titanium Hot-rolled plates	(4~100)mm×(800~2600)mm×(2000~12000)mm
Titanium Cold-rolled Sheet	(0.01~4.0)mm×(800~1560)mm×( ~6000) mm
Titanium Foil / Strips	(0.01~2.0)mm×(800~1560)mm×L
Titanium Tubes / Pipes	Ф(3~114)mm×( 0.2~5)mm × (~15000)mm
Standards	GB,GJB,ASTM,AMS,BS,DIN,DMS,JIS,ГОСт
Titanium Grade	GR1,GR2,GR3,GR5,GR7,GR12 BT1-00,BT1-0,BT1-2 TA0,TA2,TA3,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4

Titanium Production Process

Titanium Production Equipment

Welcome to conact

us for titanium inquiry

Pure titanium is a silver-white metal with many excellent properties. The density of titanium is 4.54g/cm3, which is 43% lighter than steel and slightly heavier than the prestigious light metal magnesium. The mechanical strength is about the same as that of steel, twice that of aluminum and five times that of magnesium. Titanium is resistant to high temperatures, with a melting point of 1942K, which is nearly 1000K higher than gold and nearly 500K higher than steel.

Standard of titanium wire
GB/T, GJB, AWS, ASTM, AMS, JIS
Grade of titanium wire
American label number: GR1, GR2, GR3, GR5, GR7, GR12, Ti6AL4V ELI, Ti6AL7Nb, Ti13Nb13Zr, Ti1533
Russian label number: BT1-00, BT1-0, BT1-2, etc.
Domestic brands: TAO, TA1, TA2, TA3, TA4, TA5, TA6, TA7, TA9, TA10, TB2, TC1, TC2, TC3, TC4, TC4ELI, TC11,
Surface of the titanium wire
Pickled surface Bright surface
Application of Titanium wire
Military, medical, sporting goods, glasses, earrings, headgear, electroplating hangers, welding wire and other industries.
State of titaniu Plate
Annealed state (M) Hot processed state (R) Cold processed state (Y) (annealed, ultrasonic flaw detection) Solid solution state(ST)

Over the years, we have worked hard to promote and realize the modernization of alloy sales, and actively cultivated and enhanced the ability of employees' independent innovation. All-round renovation and upgrade of the original business site, facilities and equipment, and modern computer management. Hope to establish long-term partnerships and win market reputation.

We are increasing thescale of trade and customers through out the world. With our good reputation we have won the trust of our customers. It's helps the modernisation of our country and promote the economic and technical exchanges with the rest of the world. We also look forward to enhance the friendship with other countries and make positive impact.

We warmly hope that you and us together, hand in hand, create a glorious future.

How can I contact with your company?
telephone.

What is your working time?

Monday-Friday : 8:30AM-17:00PM (Beijing time, GMT+08.00)

We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . Pls e-mail us during our holiday if u have any questions.

What is your payment terms?

T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal

What is the lead time?

Usually sample lead time is 15 days after payment has been confirmed.
