Home > Products > BENTLY NEVADA > BENTLY NEVADA 21000-16-05-00-085-03-01
BENTLY NEVADA 21000-16-05-00-085-03-01
- 1000 Piece / Pieces per Month
- Xiamen
- T/T
- 3 days
You May Like
Product Description
Contact Me ! | |
Sales manager: Jane Li Mobile/whtasapp : +86 18950128464 Email: sales5@askplc.com
| |
Product information | |
Manufacturers： Bently Nevada Part number：21000-16-05-00-085-03-01 Condition：Brand New Lead time: 1-2 working days. Type of payment:T/T and Western Union. Courier partners: DHL, UPS, TNT, FedEx and EMS. Technical specification, manuals and data sheets: Available on request. Probe Option with Connector: 15 = 3300 XL 5 mm probe Probe Cable Length Option: 04 = 4.0 metre (157 in) Standoff Adapter: 00 = No standoff adapter Probe Penetration: 015 = 1.5 in Fittings Option: 00 = No additional fittings Mounting Thread Option: 02 = 3/4-14 NPT (required when no standoff adapter is used) Material: Aluminum housing with 304 stainless steel sleeve | |
Ordering Information |
For the detailed listing of country and product specific approvals, refer to the Approvals Quick Reference Guide (108M1756) available from . |
Proximity Probe Housing Assemblies
21000 - AA-BB-CC-DDD-EE-FF
A: Probe with Connector | |
00 | Probe not required |
14 | 420 nuclear |
15 | 300 nuclear |
16 | 3300 XL 8 mm probe |
26 | 3300 XL NSv probe |
27 | 3300 XL NSv probe, selectable hazardous area approvals |
28 | 3300 XL 8 mm probe, selectable hazardous area approvals |
29 | 3300 XL 11 mm probe |
30 | 3300 XL 11 mm probe, selectable hazardous area approvals |
31 | 3300 XL NSv probe with connector protector |
32 | 3300 XL NSv probe with connector protector, selectable hazardous area approvals |
33 | 3300 XL 8 mm probe with connector protector |
34 | 3300 XL 8 mm probe with connector protector, selectable hazardous area approvals |
35 | 3300 XL 11 mm probe with connector protector |
36 | 3300 XL 11 mm probe with connector protector, selectable hazardous area approvals |
37 | 3300 XL 8 mm probe, ETR, selectable hazardous area approvals (available for 21000 only) |
B: Probe Cable Length | |
00 | Probe cable not required |
05 | 0.5 m (20 in) |
10 | 1.0 m (39 in) |
12 | 12.0 in |
18 | 18.0 in |
24 | 24.0 in |
30 | 30.0 in |
36 | 36.0 in |
C: Standoff Adapter Length (Option C Dimension) | |
Must be ordered if Standoff Adapter Length option is not 00. | |
15 | Minimum length 1.5 in (38 mm) |
75 | Maximum length 7.5 in (191 mm) |
Recommendation Order in increments of 0.5 in (13 mm) | |
Examples 1.5 in (38 mm) = 15 No standoff adapter = 00 | |
D: Probe Penetration (Option D Dimension) | |
10 | Minimum length 1.0 in (25.4 mm) |
Other | |
Recommendation Order in increments of 0.1 in (3 mm) | |
Examples 3.7 in (94 mm) = 037 2.4 in (569 mm) = 224 | |
Probe P/N and S/N may be displayed on a flag label for some combinations of the C plus D options where only a small section of the probe cable is visible. |
For probe penetration lengths between 1.0 and 2.0 inches, it may be necessary to counter bore the machine case to reduce probe side view or rear view effects |
If you select a probe penetration length (C plus D) greater than 300 mm (12 in), you must add sleeve support near the probe to prevent resonance from occurring. Adjustment range of probe penetration option D is 13 mm (± 0.5 in). For the maximum value of C plus D, See 21000/CA21000 Dimensions on page 15.. |
E: Fittings | |
00 | Without fittings |
01 | One explosion-proof fitting and one plug |
02 | Two explosion-proof fittings |
03 | One 3/4-14 NPT plug One 3/4-14 to 1/2-14 NPT reducer One cable seal grip with grommets for the following cable sizes: ? 1/8 to 3/16 inches ? 1/4 to 5/16 inches ? 5/16 to 3/8 inches |
04 | One 3/4-14 NPT plug only |
Although explosion-proof fittings are available for all housings, only CA versions of the housing are rated as explosion-proof by CSA when ordered with the E:00, E:01, E:02, or E:04 options. |
F: Mounting Thread | |
01 | As cast without threads |
02 | 3/4-14 NPT |
03 | Will default to 02 option if C:Option Standoff Adapter Length option is not 00. |
04 | 1/2-14 BSP |
