Parker 690 Series AC Drives 690-233130F1-B00P00-A400

Legacy Part Code：690PF/0370/230/0011/UK/0/0/0/BO/115/0

Part Code：690-233130F1-B00P00-A400

Parker 690 Series AC Drives – 3PH, 230V – 37kW, Frame F – 1PH, 115V Aux – Brake Switch Fitted – No Filter – No System Board – Panel Mount – No Special Options – English (50Hz) – Parker 6901 Keypad – No Speed Feedback – No Comms.

The Range:
The 690 range is a Parker SSD Inverter circa 1993 – 1999.

Frame Sizes:
Below are the power ratings for the different options and frame sizes. TOF = Top of Frame.

1PH, 230V
Frame B (0.75, 1.5, 2.2) kW [TOF: 690-212105B0-B00P00-A400]

3PH, 230V
Frame B (0.75, 1.5, 2.2, 4) kW [TOF: 690-232165B0-B00P00-A400]
Frame C (5.5, 7.5) kW [TOF: 690-232280C0-B00P00-A400]
Frame D (11, 15, 18.5) kW [TOF: 690-232680D0-B00P00-A400]
Frame E (22) kW [TOF: 690-232800E0-B00P00-A400]
Frame F (30, 37, 45) kW [TOF: 690-233154F1-B00P00-A400 / 690-233154F2-B00P00-A400]

3PH, 400V
Frame B (0.75, 1.5, 2.2, 4, 5.5, 6) kW [TOF: 690-432140B0-B00P00-A400]
Frame C (5.5, 7.5, 11, 15) kW [TOF: 690-432300C0-B00P00-A400]
Frame D (15, 18.5, 22, 30) kW [TOF: 690-432590D0-B00P00-A400]
Frame E (30, 37, 45) kW [TOF: 690-432870E0-B00P00-A400]
Frame F (55, 75, 90) kW [TOF: 690-433180F1-B00P00-A400 / 690-433180F2-B00P00-A400]
Frame G (132, 180) kW [TOF: 690-433361G1-B00P00-A400 / 690-433361G2-B00P00-A400]
Frame H (220, 250, 280) kW [TOF: 690-433520H1-B00P00-A400 / 690-433520H2-B00P00-A400]
Frame J (315) kW [TOF: 690-433590J1-B00P00-A400 / 690-433590J2-B00P00-A400]

3PH, 500V
Frame B (2.2, 4, 5.5) kW [TOF: 690-532110B0-B00P00-A400]
Frame C (5.5, 7.5, 11, 15) kW [TOF: 690-532270C0-B00P00-A400]
Frame D (15, 18.5, 22, 30) kW [TOF: 690-532520D0-B00P00-A400]
Frame E (30, 37, 45) kW [TOF: 690-532870E0-B00P00-A400]
Frame F (55, 75, 90) kW [TOF: 690-533156F1-B00P00-A400 / 690-533156F2-B00P00-A400]

Frame Dimensions:
Frame B (176.5(W) x 233(H) x 181(D) mm) – approx. 4.3kg
Frame C (201(W) x 348(H) x 208(D) mm) – approx. 9.3kg
Frame D (252(W) x 453(H) x 245(D) mm) – approx. 18.4kg
Frame E (257(W) x 668.6(H) x 312(D) mm) – approx. 32.5kg
Frame F (257(W) x 720(H) x 355(D) mm) – approx. 41kg
Frame G (456(W) x 1042(H) x 465(D) mm) – approx. 108kg
Frame H (572(W) x 1177(H) x 465(D) mm) – approx. 138kg
Frame J (1177(W) x 1288(H) x 465(D) mm) – approx. 176kg

Options:
There are a number of language options available for each drive. All drives must now be sold with Keypads. There are a number of purchasable additional options for the 690 listed below:

Note: the last 2 digits of the part number denote the purchasable options. These will be referred to as option X & Y (XY). Digit 14 of the part number also defines whether the unit is fitted with a ‘system board’.

System Board
0 – No System Board
S – System Board Fitted [LA467471U002 (for Frame B) / LA503493 (for Frame C – K)]

Option X
0 – None
3 – HTTL Encoder [6054-HTTL-00]

Option Y
0 – None
C – ControlNet [6053-CNET-00-G]
D – DeviceNet [6055-DNET-00]
E – Ethernet [6055-ENET-00]
J – Johnson Metasys [6055-JMET-00]
L – Link [6055-LINK-00]
M – ModBus+ [6055-MBP-00]
N – CanOpen [6055-CAN-00]
P – Profibus [6055-PROF-00]
R – RS485 [6055-EI00-00]
S – Siemens Apogee [6055-APOG-00]
W – LonWorks [6055-LON-00]
