nanshan AKLU 75 Engineering Series Aluminum Profiles

It comes from China's largest aluminum profile production base, with an annual output value of up to 3 million tons. The high starting point has created a complete aluminum processing industry chain with the shortest distance in the same region of the world, including thermoelectricity, alumina, electrolytic aluminum, casting, aluminum profile/hot rolling-cold rolling-foil rolling, and waste aluminum recycling (recycling). The company has always adhered to the development strategy of "innovation-driven, high-end manufacturing, and deep processing". The terminal products are widely used in aviation, automobiles, rail transportation, ships, energy, petrochemicals, containers, industrial profiles, fine civil profiles, high-end system doors and windows, container cans, food packaging, battery foil, aluminum deep processing and other fields. The products are sold all over the world and can be customized according to customer needs.

AKLU 75 series engineering energy-saving doors and windows

  AKLU75 series are energy-saving single-body doors and windows with a flush design to enhance the aesthetic appearance. The corner assembly adopts the corner injection process; the middle support connection adopts the end surface glue treatment process; the insulation strip adopts a multi-cavity design to enhance the waterproof, airtight, heat insulation and sound insulation performance. Standard configuration: steel sheet, anti-sinking block.

Basic configuration parameters :

size : 75mm × 50mm × 30mm

Center frame size : 75mm × 73mm × 30mm

Inner opening size: 85mm × 50 mm × 38mm

Profile wall thickness: 1.4mm 1.8mm 2.2mm

External opening size: 85mm × 78 mm × 33mm

Glass notch : 43mm-63mm

Glass specifications: 5+12A+5+12A+5mm, 6mm+9A+6+9A+6 optional

Insulation strip material: PA66 nylon strip

Thermal insulation strip width: 34mm, can be equipped with multiple cavities

Sealing strip material: EPDM rubber strip

Hardware configuration: Standard AKLU European standard notch

Opening method: Inward opening, outward opening, inward opening and tilting, outward opening and hanging

Product performance parameters:

Air tightness: National standard GB/T 31433-2015, test result is level 8

Water tightness: National standard GB/T 31433-2015, test result is level 8

Wind pressure resistance: National standard GB/T 31433-2015, test result is level 8

Thermal insulation: National standard GB/T 31433-2015, test result is level 8

Sound insulation: National standard GB/T 8485-2008, test result is level 3 ≤ 40db
