ASTM A213 Tubes, ASTM A213 Pipes, ASME SA213 Tubes, ASMT A213 Boiler Tubes, A213 Heat Exchanger Tubes, A213 Super Heater Tubes, ASTM A213 Tubing

ASTM A213 specification covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes. Grades containing the letter H in their designation have requirements different from those of similar grades not containing the letter H. These different requirements provide higher creep-rupture strength than normally achievable in similar grades without these different requirements. The tubes shall be made by the seamless process and shall be either hot finished or cold finished, as specified.

Prosaic Steel and Alloys in store for our clients a sturdy range of ASTM A213 Stainless Steel Pipes and ASTM A213 Stainless Steel Tubes that are capacitated to withstand temperature variations and thus are used in heat transfer process equipment like boilers, super heaters, heat exchangers, condensers and similar applications. These stainless steel pipes can be customized depending upon their industrial usage and hold the following technical details:

Prosaic Steel and Alloys Manufacture and Supply ASTM A213 TP304, ASTM A213 TP304L, ASTM A213 TP304H, ASTM A213 TP309S, ASTM A213 TP310, ASTM A213 TP310S, ASTM A213 TP316, ASTM A213 TP316L, ASTM A213 TP316H, ASTM A213 TP317L, ASTM A213 TP321, ASTM A213 TP321H, ASTM A213 TP347, ASTM A213 TP347H, ASTM A213 TP904L

Sizes (Seamless): 1/2” NB - 24” NB
Sizes (ERW): 1/2” NB - 24” NB
Sizes (EFW): 6” NB - 100” NB

Wall Thickness available:
Schedule 5S - Schedule XXS (heavier on request)

1.1 This specication2 covers seamless ferritic and austenitic steel boiler,superheater, andheat-exchanger tubes, designated Grades T5,TP304, etc. These steels are listed in Tables 1 and 2.
1.2 Grades containing the letter, H, in their designation, have requirements different from those of similar grades not containing the letter, H. These different requirements provide higher creep-rupture strength than normally achievable in similar grades without these different requirements.
1.3 The tubing sizes and thicknesses usually furnished to this specication are 18 in. [3.2 mm] in inside diameter to 5 in. [127 mm] in outside diameter and 0.015 to 0.500 in. [0.4 to 12.7 mm], inclusive, in minimum wall thickness or, if specied in the order, average wall thickness. Tubing having other diameters may be furnished, provided such tubes comply with all other requirements of this specication.

• 1. The values stated in either SI units or inch-pound units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard. The inch-pound units shall apply unless the “M” designation of this specication is specied in the order.

• 2. Referenced Documents

1 This specication is under the jurisdiction of ASTM Committee A01on Steel,Stainless Steeland Related Alloys and is the direct responsibility of Subcommittee A01.10 on Stainless and Alloy Steel Tubular Products.
Current edition approved April 1, 2009. Published April 2009. Originally approved in 1939. Last previous edition approved in 2009 as A 213/A 213M – 09.
2 For ASME Boiler and Pressure Vessel Code applications see related Specication SA-213 in Section II of that Code.
3 For referenced ASTM standards, visit the ASTM website, , or contact ASTM Customer Service at ForAnnualBookofASTM Standards volume information, refer to the standard’s Document Summary page on the ASTM website.
A 262 Practices for Detecting Susceptibility to Intergranu lar Attack in AusteniticStainless Steels
A 941 Terminology Relating to Steel,Stainless Steel, Re lated Alloys, and Ferroalloys
A 1016/A 1016M Specication for General Requirements for Ferritic AlloySteel, Austenitic Alloy Steel, and Stainless Steel Tubes
E112 Test Methods for Determining Average Grain Size
3. Terminology

• 1.Denitions—For denitions of terms used in this specication, refer to Terminology A 941.

• 2. Ordering Information

4.1 It shall be the responsibility of the purchaser to specify all requirements that are necessary for products under this specication. Such requirements to be considered include, but are not limited to, the following:
4.1.1 Quantity (feet, metres, or number of lengths),
4.1.2 Name of material (seamless tubes),
4.1.3 Grade (Tables 1 and 2),
4.1.4 Condition (hot nished or cold nished),
4.1.5 Controlled structural characteristics (see 6.3),
4.1.6 Size (outside diameter and minimum wall thickness, unless average wall thickness is specied),
4.1.7 Length (specic or random),
4.1.8 Hydrostatic Test or Nondestructive Electric Test (see 10.1),
4.1.9 Specication designation and year of issue,
4.1.10 Increased sulfur (for machinability, see Note B, Table 1, and 15.3), and

• Special requirements and any supplementary requirements selected.

• General Requirements

5.1 Product furnished to this specication shall conform to the requirements of Specication A 1016/A 1016M, including any supplementary requirements that are indicated.

• Nominal Pipe Size(NPS): 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2 inch

• Outside Diameter: 10,3 - 73 mm (0,405 - 2,875 inch)

• Wall Thickness: 1,24 - 7,01 (0,049 - 0,276 inch)

• Steel Grades -TP 304, TP 304L, TP 316, TP 316L, TP 321, T5, T11, T12, T13, T91

• Technical requirements acc. to ASTM A 450.

• Size of pipes in accordance with ANSI/ASME B36.19M.

• The quality of pipes is ensured by manufacturing process and non-destructive test.

• Hardness of metal not less than 100 HB.

• Length tolerance of measured pipes not greater than +10 mm.

• Monitoring of continuity of metal by pneumotest with pressure of 6 bar is available.

• Intergranular corrosion test in accordance with ASTM A262, Practice E is available.

• Weight Count:(just for Alloy Steel)

• Weight(Kg/M)=(OD-WT)*WT*0.02466, OD:Outside Diameter, WT:Wall-Thickness

• 1/2" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 3/4" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 1" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 1-1/4" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 1-1/2" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 2" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 2-1/2" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 3" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 3-1/2" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 4" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 5" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 6" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 8" NB in ThicknessSchedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 10" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 12" NB in ThicknessSchedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 14" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 16" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 18" NB in Thickness Schedule 10, Schedule 40, Schedule 80, Schedule 160, Schedule XXS

• 1/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 5/16" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 3/8" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 1/2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 3/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 1" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 1-1/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 1-1/2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 1-3/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 2-1/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 2-1/2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 2-3/4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 3" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 3-1/2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 4" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 4-1/2" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

• 5" OD in Thickness 10 Gauge, 12 Gauge, 14 Gauge, 16 Gauge, 18 Gauge, 20 Gauge, 22 Gauge

We export ASTM A213 Stainless Steel Seamless Pipe and Tube to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States Of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East.etc.

Prosaic Steel and Alloys is a well known worldwide exporter of A213 Stainless Steel Seamless Pipes and Tubes, Prosaic Steel and Alloys is committed to provide each and every customer with the highest standard of customer service. We deals in A213 Stainless Steel Seamless Pipes in India & Overseas, offering a wide range of A213 Stainless Steel Seamless Pipes and Tubes.
