Squeeze Peristaltic Extruded Pump Extruded Hose
- Tianjin shanghai qingdao shenzhen
- T/T
- 5 days
You May Like
-
Industrial Peristaltic Pump Squeeze Hose
-
Peristaltic Squeeze Extruded Pump Rubber Hose for Cement Mortar Conveyor
-
Concrete Cement Extrusion Pump Hose for Peristaltic Pump Hose
-
Concrete Pump Hose, Extruded Mortar Pump Extruded Rubber Hose
-
Rubber extrusion hose for peristaltic pump used for pumping mud
-
Squeezing hose Squeezing pump Concrete pump Squeezing hose
Product Details
| Brand Name | Biaohui | Place of Origin | China | |
| Model Number | 10mm to 125mm | Name | Peristaltic Pump Hose | |
| Reinforcement | Fibber Braid or Spiral | Inner Rubber Tube | Nr,SBR,EPDM Blend Rubber | |
| Cover Rubber | Cr, NBR, EPDM, Nature Rubber Blend Rubbe | Application | Air Water Delivery Hose for Industrial | |
| Surface | Cloth or Smooth | Temperature Range | 30 Deg to 121 Deg Can Be OEM | |
| Performance | Black Abrasion, Corrosion and Oil Resis |
Product Description
Rubber Hose Used for Industrial Peristaltic Pump
Peristaltic Pump Hose is the par in a peristaltic pump. There the rotor with a number of rollers or shoes compresses the tubing and forces liquid to move. It is made from extremely flexible rubber (natural rubber, NBR, CSM, EPDM, silicone and others). While it resists compression, friction and chemical. They can be textile reinforced.
Construction:
Tube: Black and smooth rubber compound
Reinforce: Multiply of heavy duty cord
Cover: Black synthetic rubber; Wrapped
Application:
The peristaltic pump hose is specially designed for peristaltic pump. It is designed with long service life and min cost.
Characteristic:
●Extremely durable; High abrasion, ozone & weather resistance.
●The lowest possible friction between the hose and roller
Temperature: -40℃ to +100℃
| Model | Inner diameter of hose(mm) | Outer diameter of hose(mm) | Length of hose(mm) | Material of hose |
| 10 | 10 | 26 | 480 | |
| 20 | 20 | 42 | 720 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 25 | 25 | 49 | 900 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 32 | 32 | 66 | 1080 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 40 | 40 | 66 | 1240 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 50 | 50 | 84 | 1595 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 65 | 65 | 100 | 1840 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 75 | 75 | 116 | 1870 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 90 | 90 | 135 | 2970 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 100 | 100 | 145 | 3230 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
| 125 | 125 | 176 | 4075 | NR/NBR/EPDM/CSM/F-NR/F-NBR |
Hebei Biaohui Rubber and Plastic Products Co., Ltd. main products include TPU flat hose series, fire hose series, industrial hose series, material conveying hose series, silicone hose series, metal hose series, PTFE hose series and matching joints, various rubber and plastic products and hose products.
