High-Efficiency Single Shaft Shredder for Industrial Waste Reduction

S Series Single Shaft Shredders from Zibo United Tech Machinery Co., Ltd. are versatile size reduction machines suitable for processing a wide range of materials to a uniform particle size.

Single shaft shredder is available to recycle wide range of material.It is an ideal machine for plastic, paper, wood, fiber, rubber, organic waste a wide variety of non-metallic materials.As per our customer’s requirements, such as the input size of materials. Capacity and the final output size etc. We could work out a suitable proposal for our clients. After being shredder by the machine, the output material could be used directly or go int to the next step of size reduction.

Our Single Shaft Shredder is engineered for superior performance, featuring a robust cutting chamber and advanced blade technology. Ideal for industrial waste management, it efficiently processes materials like plastics, rubber, and organic waste, ensuring high throughput and low energy consumption.

With the function of PLC system, it is possible to control automatically start, stop. Automatic reverse sensors to protect the machine against over loading and jamming. Throughputs typically range between 300kg/hr — 15,000kg/hr+ depending on the model, material type and application.

We have special models are available for specific applications such as pipes and other bulky materials shredding.

The wide range of machine sizes and various configurations guarantees optimum performance in every application.

Single shaft shredders can either be feed manually or bulk loaded using materials handling equipment. Various options are available for transporting materials to and from the shredders including belt conveyors, screw conveyors and air extraction systems.

Single Shaft Shredder Advantages:

* Detachable rotor blade, easy disassemble and installation, and simple maintenance.

* Automatic feeder, increase produce efficiency.

* Quick change screen for accurate particle size control.

* Shock absorbing gearbox reduces stress on drive components.

* Integrated rotor, assured the cutter clearance between the rotor blade and the counter blade.

* Enclosed bearing protection design, waterproof and dustproof, extend the bearing work life.

* PLC control system, automatic reverse sensor to protect the machine against over loading and jamming.

* Provide the rotor cooler system against the low melting materials, prevent the materials burning while the temperature higher.

Applications:

· Plastics — various rigid and flexible plastics including Moldings, Purging/Lump, Profiles, Films etc.

· Timber/Wood — Pallets, Joiners Waste, Green Waste etc.

· Paper & Cardboard — Confidential Documents, Production Waste, Packaging Materials etc.

· Rubber — Skeletal Scrap, Production Waste etc.

· Non Ferrous Metals:-

· Copper Cable — Household, Telecoms and Industrial Cables including S.W.A.

· Aluminum — Used Beverage Cans (UBC's), Swarf, Cables etc.

· Textiles — Carpet (Rolls & Tiles), Garments etc.

· Security Destruction — Counterfeit Items, Faulty Goods, Out of Date Stock etc.

· Foam — Production Waste etc.

· Mixed Household & Commercial Waste — RDF/SRF Production

Note:

1. The voltage about the power supply can be selected by the customer’s specific requirements.

2. The shredder capacity can be influenced by the material compostion and output size.

The above specifications are only for reference and subject to change without prior notice, please confirm with our sales representative when making order.

Our service:
(1) Your inquiry related to our products or prices will be replied in 12hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
