Free Sample DN-30GDV17-BZ30 / DCN-30DV1-2 Soldering Tips Cartridge for Apollo Soldering Robot Welding Soldering Tips DN Series Apollo Seiko Tips

Specifications of Apollo Seiko Tips Cartridge DN-30GDV17-BZ30 / DCN-30DV1-2

• One side tinning

• DC48V,  Total Length: 101mm

• Diameter: 6.4mm

• Tip width: a: 5mm, b: 3mm

• Tip thickness (c): 1 mm

• Tin area, two side (d): 3 mm

• Choice: Black Tip

• Lead Time: 1~2 Weeks

• Material: Copper

• Apllication: For all Apollo Seiko soldering robot

• Advantage: up to 300 degree centigrade in 6 seconds

• Custom-made service available

Advantages of YINATE Soldering Tips

Features of Apollo Seiko Soldering Robot Tips

*Designed to meet Lead free soldering requirements.
*A high precision thermocouple is built in to the Top of the iron tip, a minimal temperature drop can be quickly detected and recovered, temperature can reach 300° C within 6 seconds.
*Quick change cartridge type iron provides for consistent location and height adjustment with each tip change.

Apollo Soldering Robot Tips Standard Models

D series: 08D, 10D, 13D, 16D, 20D, 24D, 30D, 40D, 50D, 60D, 80D
D-2 series: 08D-2, DV10D-2, 13D-2, 16D-2, 20D-2, 24D-2, 30D-2, 40D-2, 50D-2, 60D-2
DV2 series: 13DV2, 162, 20DV2, 24DV2, 30DV2, 40DV2, 50DV2
DV1 series: 10DV1, 13DV1, 16DV1, 20DV1, 24DV1, 30DV1, 40DV1, 50DV1
BCV1 series: 20BCV1, 24BCV1, 30BCV1, 40BCV1
DV1-2 series: 10DV1-2, 13DV1-2, 16DV1-2, 20DV1-2, 24DV1-2, 30DV1-2, 40DV1-2, 50DV1-2, 60DV1-2, 80DV1-2
PC series: 10PC, 13PC, 16PC, 20PC, 24PC, 30PC, 40PC, 50PC, 60PC
PVC series: 20PVC2, 24PVC2, 30PVC2, 40PVC2, 50PVC2
FPR series: 16FPR, 20FPR, 24FPR, 30FPR, 40FPR, 50FPR
R series: 20R, 24R, 30R, 40R, 50R
UPL series: 16UPL, 22UPL, 32UPL

Product Pictures of Apollo Seiko DCN Series Soldering Tips
