Reverse dutch twilled weave wire mesh weaving machine
- 100 Set / Sets per Month
- XINGANG PORT, TIANJIN, CHINA
- T/T L/C Other
- 60 days
You May Like
-
Super Duplex Stainless Steel Wire Mesh Weaving Machines
-
Lanying wire mesh machine
-
hebei lanying technology wire mesh machine
-
Five heddle weave wire mesh machine five shaft wire mesh machine
-
Shuttleless PLC wire mesh weaving machine loom for India market
-
LANYING woven wire mesh machine SG130/130-1JD for industrial woven wire cloth fabric weaving
Product Details
| Brand Name | LANYING WIRE MESH MACHINE | Place of Origin | China | |
| Model Number | SG180 SERIES | Material | Galvanized Steel Wire | |
| Type | Weave Wire Mesh | Application | Filters | |
| Technique | Woven | Wire Diameter | 0.2-1.2MM | |
| Weave Style | Other, PLAIN, TWILL, DUTCH, RDW，etc |
Product Description
lanyingmachine
SG180 Series Weaving Machine
SG180 Series CNC metal wire mesh weaving machine is suitable for super heavy wire mesh weaving, there are single beat-up and double beat-up type. It can weave wire materials such as stainless steel, iron, bronze, aluminum, alloy, nickel, polyester,etc.
Product Series | SG100 Series | SG130 Series | SG160 Series | SG180 Series |
Standard weaving width (Special width on request)
| 1300mm 1600mm 2000mm | 1300mm 1600mm 2000mm 2500mm 3000mm | 1300mm 1600mm 2000mm 2500mm 3000mm | 1300mm 1600mm 2000mm 2500mm 3000mm 4000mm |
Wire diameter range | 0.016-0.3mm | 0.06-0.45mm | 0.1-0.7mm | 0.2-2.1mm |
Plain weave square hole (mesh/inch) | 40-400 | 20-260 | 10-100 | 6-60 |
Twill weave (mesh/inch) | ≤600 | ≤400 | ≤350 | ≤260 |
Wire material | Stainless steel, iron, copper, aluminum, platinum, nickel, polyester | Stainless steel, iron, copper, aluminum, | Stainless steel, iron, copper, aluminum, | Stainless steel, iron,copper, aluminum, |
Speed | 100 rpm | 100 rpm | 50-70 rpm | 35-50 rpm |
Wire diameter | 0.2-2.1mm | |||||
Weaving density | Plain weave square hole 6-60 or 2-40mesh/inch; twilled weave up to 260mesh/inch | |||||
Nominal width (special width on request) | 1.3m | 1.6m | 2m | 2.5m | 3m | 4m |
Speed(the actual speed depends on the weaving specs and width) | 46-55RPM | 46-55RPM | 40-50RPM | 32-35RPM | 30-35RPM | 25-30RPM |
Total power | 13KW | 13.5KW | 16KW | 17KW | 17.5KW | 18KW |
Size (L*W*H) mm | 3500X3860X2160 | 3500X4160X2160 | 3500X4560X2160 | 3500X5600X2160 | 3500X5560X2160 | 3500X5560X2160 |
Weight | 10000KG | 13000KG | 14000KG | 18000KG | 19000KG | 21000KG |
