Product Details
| Brand Name | BOLI | Place of Origin | China | |
| Model Number | BOLLSS-304SS | Material | Other, stainless steel |
bag,wooden pallet, wooden box.
Product Description
| Layers: | Bunk |
| Usage: | Liquid Filter, Air Filter, Solid Filter |
| Type: | Mine Sieving Mesh |
| Hole Shape: | Diamond |
| Structure: | Single Network |
We manufactures purpose-made filters, pressings and filter elements to customers' specifications. Facilities including welding, spot welding, seam welding and press forming.
We offer wire cloth processed welded filter tubes, cylinders and other filter elements. Custom order widths & lengths are available.
Other facilities include the high speed cutting of stainless steel or plain discs, together with a variety of shaped screens. These can be supplied as separate components or combined in varying meshes, spot welded together or bound with aluminium, stainless steel rims to form multi-layer screen packs and spinneret filters.
Product Details
material :stainless steel SUS 304, 304L, 316, 316L, copper,nickel,titanium
mesh type: plain weave woven wire mesh, twill weave woven wire mesh, perforated metal, expanded mesh.
Layer No :one layer, two layer, or multi-layer, in multi-layer filter tube, perforated stainless steel mesh and expanded metal usually for the supporting net and the outer protective cover.
Shape: round, rectangle, loop, oval and kidney-shaped, etc
Special-shaped filter cartridges, conical filter tube, basket filter cartridges, multi-layer mesh filter cartridges , bakset type, bucket type or container type
We can manufacture filter as your requirement .Please kindly advise photo and size . Welcome OEM & ODM !Kindly inform us following information
1,Drawing
2,ID,OD,Height
3,Filtration Precision
4,End Cap
5. Custom made accept
The basket filter stainer is generally named after the handle is installed on the flange. The style is generally welded to the flange of the stainless steel filter cylinder, and the handle is welded on the flange to facilitate replacement.
The basket filter is generally divided into two types, flat and oblique, which are mainly used in the basket filter.
From the point of view of the filtering method, it can be generally divided into two types: internal in and out and out in and out. According to the specifications and parameters, the basket filter is selected. This is the most important link because it is actually In production, the loss of waste and energy is invisible, which increases the cost and causes the price of the product to increase. Therefore, it is necessary to select raw materials, improve the production skills of production employees, and reduce costs.
The inclined-type basket filter must be pre-measured according to the size and specifications during production and processing in order to determine the size of the blanking. At the same time, the flange must be carefully cut and welded when welding. Welding, to avoid damage.
Specifications --- 180 micron Stainless steel 304 and 316L basket filter stainer made in China
Application:
filter strainer is widely used in petroleum, pulp mills, perforated flask, silencer, chemistry industry, oil or lube filtration industries, aviation, oil well, electronics, electric power, metallurgy, machine, pharmaceutical, environmental protection, nuclear power, nuclear industry,natural gas, sewage or purified water treatment, refractory materials, automobile industries for distillation, absorption, evaporation and filtration processes, so as to eliminate the impurity and foam mixed in the gas and liquid.
Filtration of air: air filters, vacuum filters, filtration of corrosive gases, cage ventilation, etc.
Filtration of liquid: ceramics polluted water cleaning, beverage, disposal of sewage water, filtration of corrosive liquids, beer brewing filter, etc.
Filtration of solid: glass, coal, food processing industry, cosmetics, fluidised beds, etc.
Filtration of oil: oil refining, hydraulic oil, oilfield pipelines, etc.
Filtration of other fields: textile industry, insulation industry, automotive industry, chemical industry, metallurgy, pharmacy, electronic field, et
We offer wire cloth processed welded filter tubes, cylinders and other filter elements. Custom order widths & lengths are available.
Other facilities include the high speed cutting of stainless steel or plain discs, together with a variety of shaped screens. These can be supplied as separate components or combined in varying meshes, spot welded together or bound with aluminium, stainless steel rims to form multi-layer screen packs and spinneret filters.
Product Details
material :stainless steel SUS 304, 304L, 316, 316L, copper,nickel,titanium
mesh type: plain weave woven wire mesh, twill weave woven wire mesh, perforated metal, expanded mesh.
Layer No :one layer, two layer, or multi-layer, in multi-layer filter tube, perforated stainless steel mesh and expanded metal usually for the supporting net and the outer protective cover.
Shape: round, rectangle, loop, oval and kidney-shaped, etc
Special-shaped filter cartridges, conical filter tube, basket filter cartridges, multi-layer mesh filter cartridges , bakset type, bucket type or container type
We can manufacture filter as your requirement .Please kindly advise photo and size . Welcome OEM & ODM !Kindly inform us following information
1,Drawing
2,ID,OD,Height
3,Filtration Precision
4,End Cap
5. Custom made accept
The basket filter stainer is generally named after the handle is installed on the flange. The style is generally welded to the flange of the stainless steel filter cylinder, and the handle is welded on the flange to facilitate replacement.
The basket filter is generally divided into two types, flat and oblique, which are mainly used in the basket filter.
From the point of view of the filtering method, it can be generally divided into two types: internal in and out and out in and out. According to the specifications and parameters, the basket filter is selected. This is the most important link because it is actually In production, the loss of waste and energy is invisible, which increases the cost and causes the price of the product to increase. Therefore, it is necessary to select raw materials, improve the production skills of production employees, and reduce costs.
The inclined-type basket filter must be pre-measured according to the size and specifications during production and processing in order to determine the size of the blanking. At the same time, the flange must be carefully cut and welded when welding. Welding, to avoid damage.
Specifications --- 180 micron Stainless steel 304 and 316L basket filter stainer made in China
| Item | Descriptions | Remark |
| Type | 180 micron Stainless steel 304 and 316L basket filter stainer made in China | |
| Material | SS 304 or SS 316 | Custom made |
| End caps | SS 304 or SS 316 | Custom made |
| Sizes | Custom made | Custom made |
| Handle | Welding by argon arc welding | |
| O-ring | high temperature 400 degree | Custom made |
| Structure | Pleated SS wire mesh | |
| Direct factory | Yes,more than 15 years filter line experiences | |
| Sample | Available |
Application:
filter strainer is widely used in petroleum, pulp mills, perforated flask, silencer, chemistry industry, oil or lube filtration industries, aviation, oil well, electronics, electric power, metallurgy, machine, pharmaceutical, environmental protection, nuclear power, nuclear industry,natural gas, sewage or purified water treatment, refractory materials, automobile industries for distillation, absorption, evaporation and filtration processes, so as to eliminate the impurity and foam mixed in the gas and liquid.
Filtration of air: air filters, vacuum filters, filtration of corrosive gases, cage ventilation, etc.
Filtration of liquid: ceramics polluted water cleaning, beverage, disposal of sewage water, filtration of corrosive liquids, beer brewing filter, etc.
Filtration of solid: glass, coal, food processing industry, cosmetics, fluidised beds, etc.
Filtration of oil: oil refining, hydraulic oil, oilfield pipelines, etc.
Filtration of other fields: textile industry, insulation industry, automotive industry, chemical industry, metallurgy, pharmacy, electronic field, et
Characteristics:
High porosity and excellent permeability.
Corrosion resistance, high or low temperature resistance, wear resistant and rust resistant
Resistant to acid, alkali
Accurate filtration precision.
Easy processing and installing.
Easy forming, painting, polishing, welding and cleaning, backwash
Firm structure and high strength
Durable and long service life
Basket filter stainer construction
The basket filter consists of the connecting pipe,main pipe,filter basket,flange,flange cover and fasteners.
When the liquid comes into the filter basket through the main pipe,the particle impurities will be trapped in the basket.The clean fluid will through the filter basket and be discharged from the outlet.When it needs to be cleaned,open the screw plug at the bottom of the main pipe rotationally,drain out the fluid.Remove the flange cover,the basket can be put in the main pipe for reuse again.So the use and the maintenance is super convenient.
Application for Basket filter strainer
1.Applicable industry:Fine chemical industry,water treatment system,papermaking,automotive industry,petrochemical,mechanical processing,coating and so on.
2.Applicable liquid:All kind of the liquid with the micro particles.
Main filtration function:Remove the big particle,clean the fluid and protect the key equipment.
3.Type of filtration:Big particles filtration.It use the reusable filter material.It should be cleaned regularly by manual.
Basket filter strainer characteristics
1. Shell material: Carbon steel or stainless steel 201/304/316
2. Filter material: stainless steel
3. Sealing material: NBR or customized
4. DN: 25-300mm
5. Pressure: 1.0Mpa, 1.6Mpa
6. Filter accuracy: 10-300mesh
Technical Parameters for basket filter strainer
1,Working temperature:≤95oC;
3,Nominal diameter:DN15-DN600;
4,Nominal pressure:PN0.6-2.5Mpa;
5,Filtration precision:50um-8000um
6,Material of housing:Q235B,304,304,316,316L;
7,Material of seal:PTFE/Rubber;
8,Form of inlet/outlet:Flange/Inner wire/Outer wire/Quick installation
9,Form of cover compression:Bolt/Quick bolt
10,Suitable viscosity(cp):1-30000
11,Form of basket:Punching mesh/Single-layer mesh/Composite mesh
Maintainance for Baskte filter strainer
The key part of this kind of the filter is the filter core.The filter core consists of the filter frame and stainless steel wire mesh.The SS wire mesh belongs to the wear parts.It needs a special protection.
After the filter has worked for some time,it will precipitates a certain amount of the impurities in the filter core.Then the pressure will be increased and the flow speed will be reduced.So we should clean the impurities in the filter core in time.
When we clean the impurities,we should be careful to assure the SS wire mesh in the filter core will not be deformed or damaged.Otherwise,when you reuse the filter,the impurities of the filtered liquid will not reach to the designed requirement.And the compressors,pump or the instruments will be destroyed.
Once the SS wire mesh has been found to be deformed or damaged,we should replace it immediately.
Product display
PACKAGE & SHIPPING
Packaging steps:
Each piece put in on carton box, wood case, Plastics Packaging, pallet, etc.
Mode of shipping:
Shipping by air, sea or car.
By sea for batch goods;
Customs specifying freight forwarders or negotiable shipping methods.
Packaging steps:
Each piece put in on carton box, wood case, Plastics Packaging, pallet, etc.
Mode of shipping:
Shipping by air, sea or car.
By sea for batch goods;
Customs specifying freight forwarders or negotiable shipping methods.
Customize services
We can produce many kinds of Steel Wire Mesh products,if you have your own design or have specificationdrawing,we can make products as your requirement.
If you don't have any idea, please tell us where will it be using, we will give you some specification to refer,and we can provide the drawing also.
We can produce many kinds of Steel Wire Mesh products,if you have your own design or have specificationdrawing,we can make products as your requirement.
If you don't have any idea, please tell us where will it be using, we will give you some specification to refer,and we can provide the drawing also.
