Home > Products > Plastic Raw Materials > Polybutylene Terephthalate/PBT resin/PBTPlastic Raw Material

Polybutylene Terephthalate/PBT resin/PBTPlastic Raw Material

FOB Price

US$ 1000 - 1100 / Metric Ton

5 Metric Tons(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Kunlun

Place of Origin

China

Product description

Polybutylene telepath PBT resin for thin-walled profiles and pipes PBT for industrial functional parts

GRADE	FEATURES	APPLICATION
GF Reinforced PBT	10%-50% GF reinforced high strength, low warpage.	Electric cooker, soybean milk, and juice maker and other home appliances, air conditions shell, car accessories, fan heater, instrument panel, thermal jug... New Energy vehicle charging pile and charging gun, automotive, MCB, appliance parts, low-temperature resistant nylon tie band, power tools, office chair base, hydrant handle, ski equipment components, breaker, connector... Battery cell jar case, heating appliances case, panel, plug, electronic shell, instrument frame, auto parts and etc...

Flame Retardant PBT	Fire-resistant V0-5VA, high toughness, easy de-molding.
High-Temperature PBT	High temperature resistant 108-115 degrees centigrade.

PBT Polyethylene Terephthalate (D070830)

Product Description		Applications
·30%PBT 30% glass fiber reinforced PBT		· Injection molding
· Excellent heat stability		· Good mechanical properties balance
Properties	Test Method	Test Condition	Unit	Typical Values
Physical properties
Specific Gravity	ISO 1183	23oC	g/cm3	1.6
Ash	ISO 3451	800oC,30min	%	30
Mechanical properties
Tensile Strength	ISO 527	50mm/min	MPa	130
Elongation at Break	ISO 527	50mm/min	%	3
Tensile Modulus	ISO 527	1mm/min	MPa	10900
Flexural Modulus	ISO 178	2mm/min	MPa	5300
Charpy Notched Impact Strength	ISO 179-1eA	23oC	kJ/m2	7
Charpy Unotched Impact Strength	ISO 179-1eU	23oC	kJ/m2	45
Thermal properties
Heat deflection temperature	ISO 75	1.80MPa	C	185
Melting Point	DSC	-	C	222
Other properties
Flammability	UL94	-		1.6mmV0
Note: The data above is a typical value for reference, not a guaranteed value. The data will vary with tool design such as gate type, gate location, gate number, injection molding process, and part thickness. The data will vary with different colors as well. Prior to use the material, please consult with TOPO Co., Ltd
