TD05 16G TD05H 4G63 DSM .70 A/R 360+HP COMPRESSOR TURBO TURBOCHARGER For Mitsubishi Eclipse / Galant / Talon 2.0 DOHC 4G63
US$ 135 - 135
/ Piece
1 Piece(Min. Order)
- T/T Credit Card
You May Like
-
Turbo Type RHFV5 1515A026 1515A163 VT12 VT13 Turbocharger Mitsubishi Pajero Shogun L200 4M41
-
Turbo TD05H-16G Turbocharger 49178-01470 49178-01010 49178-01470application for Mitsubishi Various 4D31T
-
Kit Turbo Universal Turbo Supercharger Turbone Turbocharger for Sumitomo TD08 SH330 SH350 ME157213
-
TD05-20G Turbocharger for 49178-05200 MD171223 for Mitsubishi Various 4D31T Turbo With Pipe Kits
-
TF035 Turbo 49135-03500 49135-03310 49377-03030 ME201636\tturbocharger for MITSUBISHI MONTERO 2.8 TD
-
Turbo Type HX25 Turbocharger 3596586 3806298 3538993 for CUMINS 4BTA Engine
Product Description
Product Description
Specification
item | value |
Turbo Model | TD05 16G |
Condition | New |
Warranty | 12 Months |
Place of Origin | China |
Brand Name | henyee |
Engine Code | 2.0L 1997CC 122Cu. In. l4 GAS DOHC Turbocharged |
Type | Turbocharger |
Fit for | 89-94 Mitsubishi Eclipse, Eagle Talon 89-94 Plymouth Laser 95-99 ECLIPSE 2G |
Compressor Specs :
2" Compressor Inlet
16G Compressor
1.896" or 48.15mm inducer
2.670" or 67.82mm Major
Compressor 50 Trim
Turbine Specs :
12 Blade Type
2.0" Exducer
Turbine .70 A.R.
Turbine 77 Trim
2.199 " or 55.85mm Major
1.925 " or 48.90mm Minor
TD05 Exhaust Outlet Flange with 4 bolt design
16G Compressor
1.896" or 48.15mm inducer
2.670" or 67.82mm Major
Compressor 50 Trim
Turbine Specs :
12 Blade Type
2.0" Exducer
Turbine .70 A.R.
Turbine 77 Trim
2.199 " or 55.85mm Major
1.925 " or 48.90mm Minor
TD05 Exhaust Outlet Flange with 4 bolt design
Comes with internal wastegate.
All accessories included
Suggested for 1.5L to 2.3L engine up to 100-275HP
Direct bolt on to most DSM Applications (Some may require minor modifications)
