Tracked Multi-Function Loaders - Global Recruitment for B2B Partners

As a leading OEM (Original Equipment Manufacturer), we are extending a global invitation to dealers and distributors to join our esteemed partnership network. Together, let's grow our businesses and reach new heights in the industry.

jnykjx@gmail.com

skid steer loader

SLM-T360 Loader Specifications:

Product Information: ISO CE EPA EURO5
Engine Model: Kopor, Runtong, Briggs & Stratton (Three options available)
Rated Power: 13.5HP
Cylinders: 1
Intake Method: Naturally Aspirated
Emission Standard: Euro 5/EPA
Rated Load Capacity: 200 kg
Maximum Load Capacity: 300 kg
Maximum Breakout Force: 3.5KN
Bucket Capacity: 0.12m3
Traveling Speed: 6 km/h
Three-way Working Time: 9s
Operating System Pressure: 17 - 21bar
Fuel Tank Capacity: 5L
Operating Weight: 900KG
Tire Model: 15*72
Maximum Operating Height: 2450 mm
Height to Bucket Pin: 1870 mm
Overall Height: 1300 mm
Maximum Height with Bucket Flat: 1810 mm
Overall Length without Bucket: 1450mm
Overall Length with Standard Bucket: 2100 mm
Dumping Height: 1510mm
Dumping Reach: 450mm
Bucket Tilt Angle at Ground Level: 27°
Bucket Tilt Angle at Maximum Height: 114°
Wheelbase: 850mm
Ground Clearance: 150mm
Tail Length & Vehicle Width: 280mm (Note: This might be a typo, typically listed separately)
Vehicle Width: 850mm
Bucket Width: 900mm
