High Performance H1C Turbocharger 3523244 3802291 Turbo for Cummins With 4BT, 6BT Engine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Factory Price BHT3E HT4B Turbo Kits 3801590 3523591 4033537 4033537H 503801590 Turbocharger for VTA28 Engine
-
HE400VG Turbo 21953277 3781580 21953279 3781583 21972854 3781586 Turbocharger
-
Fast Delivery Turbocharger HE400VG 21953277 5353345 22215684 3791464 5353342 5328830 22215683 22215684 Turbo for Engine MD11
-
Good Quality H1C Turbo 3919113 3530714 3535417 3535454 Turbocharger for 4BT Engine
-
HE400VG Turbo Charger 21953277 3781580 21953279 3781583 21972854 3781586 Engine Parts Turbocharger
-
HE400VG Turbocharger 3791464 5353342 5328830 22215683 22215684 5353345 3791484 3791485 Auto Parts MD11 Engine
Product Description
High performance H1C turbocharger 3523244 3802291 turbo for Cummins with 4BT, 6BT engine
Welcome to contact us :
November Gao.
Mob/Wechat/WhatsApp: 8618912476630
Product description
Product description
| Part Number | 3523244 |
| Previous versions | 3523245 |
| OE number | 3802291 |
| Description | Truck, MARINE |
| CHRA | 3545699 |
| Turbo Model | H1C-8243AF/J13S5, H1C |
| Engine | 4BT, 6BT |
| Engine Manufacturer | Cummins |
| Fuel | Diesel |
| Angle α (compressor housing) | 199.5/241° |
| Angle β (turbine housing) | 301/360° |
| Bearing Housing | 3502500 (3530592, 3520574, 3530591)(1152301450) |
| Turbine Wheel | 3503798 (Ind. 70, mm, Exd. 57. mm, 12 Blades) |
| Rotor Assembly | 3545526 |
| Comp. Wheel | 3599639 (3521711)(Ind. 50. mm, Exd. 83. mm, 8+8 Blades)(1152301400) |
| Back plate | 3534947 (166537) |
| Heat shield Number | 3519302 (194149) (1152301340) |
| Repair Kit | 4027309 (3545652, 3802148)(1152301750) |
| Turbine Housing | Water Cooled |
| Gasket Kit | 3545769 |
| Gasket (turbine inlet) | 409039-0000 (312617, 2405022, 7C7431) $13.52 |
| Gasket (oil outlet) | 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) |
Application
Cummins with 4BT, 6BT engine
Product show
Packages
plastic paper, shock bubble, neutral carton,pallet or as your requirements
Company Information
CVE Electron Beam Welding from UK
Studer CNC grinding machine from Switzerland
Okuma CNC machine from Japan
Schenck balancing machine from Germany
Production capacity
Exhibition show
Booshiwheel has attended the Auto exhibition in Thailand ,Turkey,Dubai, Russia,Germany,U.S.A and Panama in 2018 year
Company Profile
1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.
2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.
3.The company's business concept are "make contribution to the development of society by technology" and "talent is the biggest and unique wealth",focus on manufacturing global the most cost-effective turbochargers.
Last ,we are looking forward to cooperating with you .
FAQ
1:Are you factory or only company?
we have factory to produce turbo products ,such as ship turbos,performance turbos,aftermarket turbos,etc .And also we have the agent for some other brand.
2:Why we can choose you?
1):Reliable-we are the real company, we dedicate in win-win.
2):Professional-we offter the turbo products exactly you want.
3):Factory-we have factory,so have compective price,fast delivery time,high quality goods.
3:How about the shipping cost?
If your goods is not large,we can send goods to you via express,such as FEDEX,DHL,EMS,TNT,etc.if your goods is large ,we will send to u via sea or air,we can quote the price base on EXW,FOB,CIF&CNF as you like, you can choose whether to use our forwarder or yours.
4:How about the price ? Can you make it cheaper?
the price depends on the item your demand quantity,Final quotation according to receiving full description of the item you want.
5:How about the sample time ?What is the payment ?
Sample time: 3-10days after e-proof confirmed and your payment received. T/T, 30% deposit ,and the balance before the shipment.
2:Why we can choose you?
1):Reliable-we are the real company, we dedicate in win-win.
2):Professional-we offter the turbo products exactly you want.
3):Factory-we have factory,so have compective price,fast delivery time,high quality goods.
3:How about the shipping cost?
If your goods is not large,we can send goods to you via express,such as FEDEX,DHL,EMS,TNT,etc.if your goods is large ,we will send to u via sea or air,we can quote the price base on EXW,FOB,CIF&CNF as you like, you can choose whether to use our forwarder or yours.
4:How about the price ? Can you make it cheaper?
the price depends on the item your demand quantity,Final quotation according to receiving full description of the item you want.
5:How about the sample time ?What is the payment ?
Sample time: 3-10days after e-proof confirmed and your payment received. T/T, 30% deposit ,and the balance before the shipment.
Welcome to contact us!
