Home > Products > Suit for construction machinery > Hx82 Gta5523BS Turbo 4955241 3104454 3104766 3104769 3594222 4042846 761064-0007 Turbocharger for Cummins Isx15, Qsx15

Hx82 Gta5523BS Turbo 4955241 3104454 3104766 3104769 3594222 4042846 761064-0007 Turbocharger for Cummins Isx15, Qsx15

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

HX82 Turbo 3594195 4025027 3596367 3596366 Qsx15 Turbocharger With QSX15 TIER 2 Engine

Welcome to contact us :

November Gao.

Mob/Wechat/WhatsApp: 8618912476630

Product description

Part Number	761064-5006S
Previous Version	761064-0005, 761064-0006, 761064-0007, 761064-6
OE number	4955240, 2868728, 2868729, 3104293, 3104294, 3104395, 3104765, 3104768, 4955240, 4956009, 3104768.0
Description	Various, Construction, JI Case, Case-IH, Cummins
CHRA	712371-0137 (712371-5137S, 3104427, 3104427RX, 3104427NX) $1,439.97 NEW IN STOCK
Turbo Model	GTA5523BS
Engine	ISX15, QSX15
Displacement	15.L, 1500 ccm
Fuel	Diesel
Angle α (compressor housing)	90°
Angle β (turbine housing)	165°
Bearing Housing	706666-0028 (Oil Cooled)
Turbine Wheel	451941-0005 (451941-0002)(Ind. 111. mm Exd. 84. mm 11 Blades)(Boreless Type)
Comp. Wheel	710081-0005 (8+8 Blades)(Boreless Type)
Back plate	706668-0008
Heat shield Number	710891-0001
Repair Kit	NEW IN STOCK
Turbine Housing	759054-0009
Turbine Housing (W. Waste Gate)	743732-0029
Compressor Cover	49168-52100 (MD613541)
Actuator	729592-0008
Turbine Housing AR	1.18
Actuator Cover	701585-0001
Gasket Kit	468190-0000 (716909-0049)
Manufacturer	Honeywell-Garrett

Applications

2006- Cummins Various, Case-IH, Cummins STX500 STX530 Tractor (4 wheel drive) With ISX15, QSX15 Engine

Product show

Packages

plastic paper, shock bubble, neutral carton,pallet or as your requirements

Company Information

CVE Electron Beam Welding from UK

Studer CNC grinding machine from Switzerland

Okuma CNC machine from Japan

Schenck balancing machine from Germany

Production capacity

Exhibition show

Booshiwheel has attended the Auto exhibition in Thailand ,Turkey,Dubai, Russia,Germany,U.S.A and Panama in 2018 year

Company Profile

1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.

2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.

3.The company's business concept are "make contribution to the development of society by technology" and "talent is the biggest and unique wealth",focus on manufacturing global the most cost-effective turbochargers.

Last ,we are looking forward to cooperating with you .

FAQ
1:Are you factory or only company?

we have factory to produce turbo products ,such as ship turbos,performance turbos,aftermarket turbos,etc .And also we have the agent for some other brand.

2:Why we can choose you?
1):Reliable-we are the real company, we dedicate in win-win.
2):Professional-we offter the turbo products exactly you want.
3):Factory-we have factory,so have compective price,fast delivery time,high quality goods.

3:How about the shipping cost?
If your goods is not large,we can send goods to you via express,such as FEDEX,DHL,EMS,TNT,etc.if your goods is large ,we will send to u via sea or air,we can quote the price base on EXW,FOB,CIF&CNF as you like, you can choose whether to use our forwarder or yours.

4:How about the price ? Can you make it cheaper?
the price depends on the item your demand quantity,Final quotation according to receiving full description of the item you want.

5:How about the sample time ?What is the payment ?
Sample time: 3-10days after e-proof confirmed and your payment received. T/T, 30% deposit ,and the balance before the shipment.
