BBQ Carbon Forming Machine

The normal package of briquetting machine meaning is wooden box (Size: L*W*H). Normally the wooden box will be fumigated according to export countries rules. If container is too tighter, we will use PE film for packing or pack it according to customers special request. Spare parts is put into wooden case or steel box, big machines loaded in container, large machines use nude packing, cover with plastic cloth. We export through Qingdao Port, also can be nominated by customer. We have superior cargo agent to arrange the sea shipment for each client, competitive price, secure transportation.

BBQ Carbon Forming Machine

BBQ Carbon Forming Machine Introduction:

(1) BBQ Carbon Forming Machine, mainly used in the production of press sludge, directly into the furnace to smelt and increase the added value.

(2) Any metallurgical industry wastes which all need to be smelted in the furnace,have to be completed by ball press machine, such as furnace dust, mud, oxide iron, steel slag, iron concentrate, aluminum ash, silicon manganese and so on.

(3) BBQ Carbon Forming Machine is widely used in metallurgy, refractories, power plant, chemical industry, energy, transportation, heating and other industries, has good economic and social benefits.

BBQ Carbon Forming Machine Customer Cautions:
(1) The particle size of the raw material should be between 0-5mm.
(2) BBQ Carbon Forming Machine can not contain impurities, especially large metal. Such as nails, or iron, rocks, it very likely damage roller and spindle..

(3) The feeding of whole production line should be stable, even, ensure workloads of dry powder briquette machine stable, to get high efficiency of production.

BBQ Carbon Forming Machine Working Principle:

(1) This series of BBQ Carbon Forming Machine will pass the powder on to the two pressure roller through the reducer.

(2)The two sides and roll rotation, in both the rotating roll, natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger.

(3)When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials becomes a finished product from the powder ball.

BBQ Carbon Forming Machine Technical Parameter:

Model: KF1450-850-350

Reducer: ZS1450

Ratio: 63

Roller Size: 850*350mm

Main Shaft Speed: 7-9r/min

Matched Power: 132kw

Capacity: 15-16t/h

Pressure Type: Constant Pressure/Hydraulic Pressure

Roller Material: 65Mn, 9Cr2Mo, high chrome alloy
