GE IS200WROBH1A is used in PDIO discrete input/output module.

GE IS200WROBH1A is used in PDIO discrete input/output module.

IS200WROBH1A changed star amount picture changed star amount picture changed star amount picture changed star amount picture changed star amount picture changed star amount picture 5.00(2) Click the star to score this product. IS200WROBH1A is used in PDIO discrete input/output module as a part of Mark VIe system. The device can be used to create TRLY relay in simplex mode. The default fuse value of IS200WROBH1A is 3.15a..

IS200WROBH1A Technical Specification Function Abbreviation/Abbreviation Fuse Value 3.15 A Manual GEH-6721L Redundancy Mode Simplex, Redundancy or TMR Terminal Board Compatibility Product Description IS200WROBH1A Board is a WROB relay fuse and power supply sensing board; Part of the Mark VIe series produced by General Electric. This board is called an optional board and can be used with several other boards in the series. All boards are used for PDIO discrete input/output modules, and the boards that WROB can connect are TDBS, SRLY and TDBT boards. The board can be used in single-module or three-module redundancy (TMR) mode. When the board is used in TMR applications, the WROB board will be installed on the TDBT board and can provide an equivalent terminal board combined with the contact input terminal board (TBCI). When the IS200WROBH1A board is connected to the TDBS board, it can convert the relay part to the same potential as the IS20TRLYH1B board. With this option, it provides inductive and fused power distribution for the first six initial relay outputs and dedicated power supply for the final relay output. The default fuse value of this board is also 3.15 amps. When the circuit board is used with the isolation voltage on TDBS, it will be used to detect the different states of six pairs of fuses on the circuit board.
