China Concrete Tensile Creep Tester LXB10 Type

Product Usage

   Used to determine the deformation performance of concrete specimens under long-term constant axial pressure.

Execution standards

   Test Code for Hydraulic Concrete SL352-2006

technical parameter

1. Test force: 100kN;

2. Measurement range: 0-100kN;

3. Pressure sensors have high resistance to eccentricity, overload, and sensitivity;

4. Relative error of pressure: ± 1%;

5. ※ Spring height: 240mm;

6. Spring material: manganese steel material, with long service life and low stress relaxation;

7. ※ Customization can be made according to the temperature requirements of the test, with the addition of a high-temperature furnace for high-temperature creep testing;

8. Compression stroke: greater than 20mm;

9. ※ Net distance for specimen operation: 1050mm;

10. Equipped with a new type of specimen balancing device, convenient for loading and leveling operations;

10. Net spacing between screws: 375mm;

11. Test block size: 100× one hundred × 400mm;

12. ※ Support size: 600× three hundred × 2200mm;

13. Working temperature: 0 ℃ -+50 ℃.

Product features

1. Fully automatic true color touch control system, real-time display of specimen status and test environment temperature and humidity;

2. The pressure plate undergoes quenching treatment process, with stable performance and small stress deformation;

3. Adopting high-quality high-speed rail springs, resistant to moisture and corrosion, with a service life of over ten years;

4. Equipped with a self-developed specialized adhesive free displacement measurement auxiliary device, which is more convenient and fast;

5. Users can make multiple specimens at the same time based on the size of each specimen, improving equipment utilization.
