RGPS Single cylinder Cone crusher

Application field：Widely used in metal and non-metallic mineral, cement, sand, metallurgical and other industries

For the material：Pebble, granite, basalt, limestone, quartz, diabase, iron ore, gold, copper, etc

Product advantage

High reliability: optimize and improve the product structure, material, processing and assembly process, so as to ensure the reliability of the use of the host

High production efficiency: the combination of scientific and reasonable crushing chamber type, eccentric distance, moving cone pendulum frequency and lamination crushing principle, through a larger quantity, good product grain type, low energy consumption

Wide adaptability: according to different feed and finished material size, match reasonable cavity type, adopt steel base frame or motor and host machine integrated installation, make installation equipment save time, lower cost

Low operating cost: specially designed cavity type and liner material make the liner utilization rate higher, and equipped with positive pressure dustproof system to ensure that the lubricating oil inside the main engine is not polluted by dust

Technical parameters

RGP100S	(c.s.s)	20 mm	25 mm	30 mm	35 mm	40 mm	45 mm	50 mm
	16mm	80-90	105-115	120-130	135-145	145-165	155-175
	20mm		120-130	145-155	160-180	170-200	185-215
	25mm			185-195	200-220	210-230

RGP300S	(c.s.s)	20 mm	25 mm	30 mm	35 mm	40 mm	45 mm	50 mm
	18mm		170-190	170-210	190-230	210-255	235-275	255-295
	25mm			220-270	255-315	290-345	320-350	330-350
	32mm				360-400	380-420	400-440
	40mm					450-500	480-530

RGP500S	(c.s.s)	45 mm	50 mm	55 mm	60 mm	65 mm	70 mm	75 mm
	18mm	300-350	325-375	375-425	400-450	425-475	450-500	500-550
	25mm		500-550	550-600	600-650	650-700	700-750	750-800
	32mm		650-700	700-750	750-800	825-875	900-950
	40mm				900-950	970-1050

Note: the production capacity of less than 4% moisture content, do not contain clay, feed particle size grading, appropriate materials is less than the discharging mouth of the feeding amount is less than 10%, feeding uniformly distributed around the crushing cavity, loose material density of 1.6 t/m after the rocks when open circuit design by quantity. Under the condition of closed circuit operation, equipment capacity by 15% to 30% higher than open operation. Due to the selected device of eccentricity, crushing ratio, feeding the hardness and the grain size of feed, feed moisture content, such as hydraulic crusher production capacity will be influenced, so the specific application, please consult us further.

Product appearance and weight

（Model）	RGP100S	RGP300S	RGP500S
kg*(Total)	7350	16200	35000
kg During the period of maintenance weight	2500	5200	11000
(Size)
A	2328	2546	3227
B	Φ1300	Φ1860	Φ2300
C	908	1401	1587
D	Φ1320	Φ1820	Φ2330
E	Φ1360	Φ1686	Φ2330
F	566	499	1275
G	1442	1582	2100
H	1400	1700	2225
I	1090	1400	1676
J**)	2416	2550	3756
J***)	2600	3230	4420
kw Motor power	75-90	200-250	200-355
Stroke options	16,20,25	18,25,28, 32,36,40	18,25,28, 32,36,40

*):Don't take parts of basic machine, given the weight of the crushing cavity with weight

**):From the top damping blocks to the hopper

***):From shock block to the hopper with a rack on the top
