Shanghai Factory aseptic brick & diamond shape carton box filling packing machine for milk/juice drinks packaging
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
juice milk aseptic brick shape carton filling machine with Paper/AL/PE laminated materais carton
-
200 to 1000ml SQ UHT milk juice drinks beverage aseptic brick shape paper carton box filling machine packing packaging machine
-
250ml base/slim/SQ juice milk aseptic brick shape carton filling machine
-
Wine milk syrup big bag in box bib filling machine
-
Automatic bag in box filling and capping bib aseptic filler for coconut water/apple juice/wine with vacuum and nitrogen
-
Cup Filling Sealing Machine Yogurt Cup Sealing Machinery Rotary Type
Product Description
Product Description
This machine is used for filling milk, fruit and vegetable juice plant protein etc. Liquid beverage by Paper aluminum plastic
composite packaging carton.
This machine is responsible for sterilizing the carton package and machine inside filling environment is aseptic, so that can make the UHT beverage after filling is aseptic, which can make the beverage shelf life is 6-12 months.
composite packaging carton.
This machine is responsible for sterilizing the carton package and machine inside filling environment is aseptic, so that can make the UHT beverage after filling is aseptic, which can make the beverage shelf life is 6-12 months.
100ml & 125ml & 150ml & 200ml & 250ml & 330ml & 500ml & 1000ml with slim shape or brick base shape or Prisma shape paper carto box.
1 Equipped with both H2O2 & UV sterilizing, comply with firm's safety management requirement.
2 The machine Automatic Form Feed –sterilize –filling –shaping – sealing
3 PLC human control, Human - Machine Interface with English and Chinese display. Intuitive operation and Low Fault rate.
4 Automatic finished all the job step, which includes run over the scroll reposefully, batch number, stick plastic tape,
chemical and physical sterilizing, roll into cylinder, filling material, sealing-off, molding, cutting and horn-shaped.
5 The forming system we choose our own patent rectangular forming method instead of roundness system. this system made the running much more stable, the function much more reliable, the exterior appearance of the product much perfect.
3 PLC human control, Human - Machine Interface with English and Chinese display. Intuitive operation and Low Fault rate.
4 Automatic finished all the job step, which includes run over the scroll reposefully, batch number, stick plastic tape,
chemical and physical sterilizing, roll into cylinder, filling material, sealing-off, molding, cutting and horn-shaped.
5 The forming system we choose our own patent rectangular forming method instead of roundness system. this system made the running much more stable, the function much more reliable, the exterior appearance of the product much perfect.
Specification
Machine Type | GY-100ml, GY-125ml, GY-150ml, GY-200ml, GY-250ml, GY-330ml, GY-500ml, GY-1000ml | ||||||
Capacity(Box Volume) | 100ml-1000ml | ||||||
Compressed Air Pressure | ≥0.6mpa(6Bar) | ||||||
Packing Speed | 3000-15000 carton/hour | ||||||
Power | 10~18KW | ||||||
Actual Power Consumption | 8KW | ||||||
Power Source | 50Hz 380/220V | ||||||
Sizes | L*W*H 4200*1800*4000mm | ||||||
Weight | 2500KG | ||||||
Package shape | Brick based shaped ,brick slim shaped |
Packing material | PE/PAPER/PE/AL/PE/PE 6layer aseptic packaging material roll |
Compressed air | 0.4-0.6Mpa,1.0m3/min |
Technological process | Feed paper---print date---sterilize---filling---shaping |
Operation model | PLC control,man-machine interface operation |
Shelf life | In 20-30℃,juice 12month ,milk 6 month |
Production Area | 100-140sq.m |
Production personal | 1-2per shift |
Final product | Drinking Milk ,Yoghurt, Juice |
STRAW APPLICATOR
CAP APPLICATOR
GENYOND MACHINERY INDUSTRIAL GROUP
It has 6 factories in China for food machine and packing machine.
Shanghai Genyond Technology Co Ltd; Zhangjiagang Genyond Machinery Co Ltd
Shanghai Jou Yu industrial Co Ltd; Shanghai Keyfood Machinery Co Ltd
Sino topone machinery; Nantong Yihai Machinery; Kunshan Kpack Machinery
Our products have been exported to more than 160 countries with Annual sales reaching 80 millions in 2022 and it raises by yearly average 10% above.
Shanghai Genyond Technology Co Ltd; Zhangjiagang Genyond Machinery Co Ltd
Shanghai Jou Yu industrial Co Ltd; Shanghai Keyfood Machinery Co Ltd
Sino topone machinery; Nantong Yihai Machinery; Kunshan Kpack Machinery
Our products have been exported to more than 160 countries with Annual sales reaching 80 millions in 2022 and it raises by yearly average 10% above.
Genyond machine has more than 100 engineers for the installation of oversea projects.
You just need to give us your idea on final product to be made, processing capacity, way of packing, we will make the proposals for your checking. You can also give us your budget, we can also design a line to meet your budget accordingly. A satisfying project will be given; A long-term cooperation will come.
You just need to give us your idea on final product to be made, processing capacity, way of packing, we will make the proposals for your checking. You can also give us your budget, we can also design a line to meet your budget accordingly. A satisfying project will be given; A long-term cooperation will come.
