RED670 Analog 16 point HART output processor
You May Like
Product Details
| Brand Name | ABB | Model Number | RED670 |
Product Description
IP30 protection level, corrugated aluminum reinforced casing, 35mm guide rail installation, DC 18-36V (9-18V optional) wide power supply, with relay alarm output, dual power redundancy, and isolation protection functions. Ci-CF110 to fiber optic supports one fiber optic interface and one bus data interface, while Ci-CF120 to fiber optic supports two cascaded up and down fiber optic interfaces and one bus data interface.
Bus data interface
*BNC-F interface form
*Supports ControlNet fieldbus protocol, communication rate: 5Mbps
*Isolation voltage: Instantaneous isolation voltage 5000V, continuous isolation voltage 1000V
*Terminal resistance: There is no terminal resistance inside this device. Please decide whether to connect it externally as needed
Fiber optic interface
*Fiber wavelength: multimode 850nm, 1310nm; Single mode 1310nm, 1550nm
*Transmission fiber: multimode 50/125um, 62.5/125um, 100/140um, single mode 8.3/125um, 9/125um, 10/125um
*Transmission distance: multimode 2km, single mode 20km, longer distance optional
*Fiber optic interface type: ST, SC, FC optional, standard ST optical interface
Power supply and protection
Contact information: 15359293870
WhatsApp:+86 15359293870
Contact person: KELLY
Email: geabbdcs@gmail.com 386353502@qq.com
Official website:
Bus data interface
*9-pin Sub_ D-jack connector, pin definition in accordance with Profibus DP protocol specifications
*Supports Profibus DP bus standard
*Signal delay (electrical port): ≤ 4Bit
*Communication speed: 9.6Kbps, 19.2 Kbps, 45.45Kbps, 93.75Kbps, 187.5Kbps, 500Kbps, 1.5Mbps, 3Mbps, 6Mbps, 12Mbps
*Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions
*Terminal resistance: This device does not come with a terminal resistance, please connect it externally as needed
Power supply and protection
*Power supply: Dual power redundant input, DC (12-36V), typical DC24V, power consumption less than 4W, with reverse protection function, industrial terminal interface
*Relay alarm output: Bus data interface fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface
mechanical properties
*External dimensions: (136x106x54) mm
*Shell: IP30 protection level, corrugated aluminum reinforced casing
*Installation method: 35mm guide rail installation
*Net weight: 800g
work environment
*Working temperature: -10 ℃~70 ℃, optional wide temperature product (-40~85 ℃)
*Storage temperature: -40 ℃~85 ℃
*Relative humidity: ≤ 90% (non condensing)
