Cold Rolled Strip Steel Filter Paper Lubricating Oil Filter Paper

Product Introduction

Cold rolled strip steel filter paper Lubricating oil filter papercharacteristics:

High tensile strength and low coefficient of variation. Advanced mesh forming technology and molding reinforcement are used to enhance and stabilize the tensile strength, maintaining the consistency between the initial strength and the strength used.

The combination of polyester fiber and polymer membrane is used for high filtration accuracy and efficiency, and the selected filtration material can meet the precision requirements specified by the user.

The filter material is not corroded by cutting fluid, does not change the chemical properties of the cutting fluid, and can be used normally within the range of -40 ℃ to 120 ℃.

The selected filtering material can withstand the mechanical forces and temperature effects of the filtering equipment, and the wet fracture strength of the filtering material used for cutting fluid will not decrease.

It is required that the filtration material has a high porosity, low filtration resistance, and a large throughput. At the same time, it requires a strong pollutant capacity, which can improve filtration efficiency, extend service life, reduce filter material consumption, and reduce filtration costs

Remarks: Suitable for filtering industrial oils such as metal cutting fluid, grinding fluid, wire drawing oil, rolling oil, grinding fluid, lubricating oil, insulation oil, etc.

Automotive parts processing, cylinder head, cylinder block, engine filtration special filter paper

Grinding machine processing cutting fluid; Grinding fluid; Special filter paper for coolant

Special filter paper for concentrated filtration of bearing machining cutting fluid and grinding fluid

Aluminum processing rolling oil; Emulsion; Grinding machine cutting fluid filter paper.

Copper processing hot rolling cooling lotion; Drawing machine lotion filter paper.

Emulsion for rolling steel processing thin plates; Grinding fluid filter paper for grinding machines.

We provide services from 7 μ~ fifty μ Various precision grade filtering consumables for vacuum negative pressure paper tape filters, Hoffman filters, and gravity paper tape filters

We can customize cutting and filtering consumables, and the paper roll can be made into various specifications, with a minimum of 400mm and a maximum of 2300mm

The paper roll has various diameters and inner diameters of various paper tubes, with a filter paper thickness of 0.12-0.49mm and a weight of 18-82g/m2,

The selection of filtering consumables is as important as the filtering equipment that is already in use. The raw materials for producing filter consumables generally include polypropylene, polyester, polypropylene, artificial fibers, polyester cellulose mixtures, etc.

The wet tensile strength of filter paper is important, as it must have sufficient strength to pull its own weight, the weight of the filter cake covering its surface, and the friction force with the chain during operation.

When selecting filter paper, the required filtering accuracy, specific filtering equipment type, coolant temperature, pH, etc. need to be considered.

The filter paper must be continuous in the length direction without any interfaces, otherwise it may cause leakage of impurities.

The filter paper should have a uniform thickness and fibers divided vertically and horizontally

The technical parameters of Cold rolled strip steel filter paper Lubricating oil filter paperare as follows
