8200-1302 Touch Screen

Supply DeviceNet fiber optic repeaters/DeviceNet to fiber optic/DeviceNet fiber optic modules;

Fiber optic interface:

*Fiber wavelength: multimode 850nm, 1310 nm; Single mode 1310 nm, 1550 nm.

*Transmission fiber: multimode 50/125 um, 62.5/125 um, 100/140 um; Single mode 8.3/125um, 9/125um, 10/125um.

*Transmission distance: Multi mode 2Km, single mode 20Km. Available for further distances.

*Fiber optic interface types: ST, SC, FC optional, standard ST optical interface.

Power supply and protection:

*Power supply: Dual power redundant input, DC (9-30) V, typical DC24V, power consumption less than 1.5W, with DC1000V voltage isolation and reverse protection function, industrial terminal interface

*Relay alarm output: Fiber optic link fault and power supply fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface

Mechanical characteristics:

*External dimensions: 132mm * 105mm * 52mm

*Shell: IP30 protection level, corrugated aluminum reinforced casing

*Installation method: 35mm guide rail installation

*Net weight: 800g

Work environment:

*Working temperature: -10-70 ℃ (-40~+85 ℃ wide temperature optional)

*Relative humidity: ≤ 90% (non condensing)

*Storage temperature: -40~80 ℃

Features:

*Supports DeviceNet bus standards. Communication rate 0-500K self negotiation

*The electrical interface has 1500V voltage isolation and 600W surge protection functions

*Adopting DC9-30V wide power input, dual power redundancy, DC1000V power isolation, reverse protection

*Single/dual optical port chain network support

*Provide relay output fiber optic link and power failure alarm

*IP30 protection level, corrugated aluminum reinforced casing, using standard industrial 35mm guide rail installation method

Data electrical interface:

*5Pin terminal interface form

*DeviceNet bus standard

*Communication speed: up to 500K,

*Equipped with overload protection and 600W surge protection;

*Terminal resistance: There is no terminal resistance inside this device. Please decide whether to connect it externally as needed

Contact information: 15359293870

WhatsApp:+86 15359293870

Contact person: KELLY

Email: geabbdcs@gmail.com   386353502@qq.com

Official website:

Bus data interface

*F-female coaxial interface form

*Supports Modicon S908 RIO fieldbus protocol, communication rate: 1.544Mbps

*Isolation voltage: Instantaneous isolation voltage 5000V, continuous isolation voltage 1000V

*Terminal resistance: There is no terminal resistance inside this device. Please decide whether to connect it externally as needed

Fiber optic interface

*Fiber wavelength: multimode 850nm, 1310nm; Single mode 1310nm, 1550nm

*Transmission fiber: multimode 50/125um, 62.5/125um, 100/140um, single mode 8.3/125um, 9/125um, 10/125um

*Transmission distance: multimode 2km, single mode 20km, longer distance optional

*Fiber optic interface type: ST, SC, FC optional, standard ST optical interface

Power supply and protection

*Power supply: Dual power redundant input, DC (9-30V), typical DC24V, power consumption less than 1.5W, with DC1000V voltage isolation and reverse protection function, industrial terminal interface

*Relay alarm output: Fiber optic link fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface

mechanical properties

*External dimensions: 136 * 106 * 54mm

*Shell: IP30 protection level, corrugated aluminum reinforced casing

*Installation method: 35mm guide rail installation

*Net weight: 800g

work
