SMD 2835 White led 0.2W
Negotiable
/ Piece
4000 Pieces(Min.Order)
- 10000000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
You May Like
Product Details
| Brand Name | SSHX | Place of Origin | China | |
| Model Number | S2835W8*** | Certification | ROHS | |
| Power | Other, 0.2W | Storage Temperature(℃) | , | |
| Operating Temperature(℃) | , | Viewing Angle(°) | 120 | |
| Emitting Color | Cool White | Chip Material | AlGaInP |
Product Description
Product Parameters
1-1 Electrical / Optical Characteristics at Ts=25°C
| Item | Symbol | Test Condition | Value | Unit | ||
| Min. | Typ. | Max. | ||||
| Forward Voltage | VF | IF=60mA | 2.8 | — | 3.4 | V |
| Reverse Current | IR | VR=5V | — | — | 10 | μA |
| Luminous Flux | Φ | IF=60mA | 25 | — | 40 | lm |
| Correlated Color Temperature | CCT | IF=60mA | 6000 | 6500 | 7000 | K |
| Viewing Angle | 2θ1/2 | IF=60mA | — | 120 | — | deg |
1-2 Absolute Maximum Ratings at Ts=25°C
| Parameter | Symbol | Rating | Unit |
| Power Dissipation | Pd | 500 | mW |
| Forward Current | IF | 60 | mA |
| Peak Forward Current | IFP | 300 | mA |
| Reverse Voltage | VR | 5 | V |
| Operating Temperature | Topr | -40～+85 | ℃ |
| Storage Temperature | Tstg | -40～+100 | ℃ |
| Junction Temperature | Tj | 115 | ℃ |
Notes：
1. 1/10 Duty cycle, 10ms pulse width.
2. The above forward voltage measurement allowance tolerance is ±0.1V.
3. The above color coordinates measurement allowance tolerance is ±0.005.
4. The above luminous intensity measurement allowance tolerance ±10%.
