Cable Strander High Speed Bearing Z-527249.ZL

Cable strander high speed bearing Z-527249.ZL

High precision bearings Z-527249.ZL 640*790*56mm must guide machine parts with high precision and support forces at up to very high speeds.Large bearings have threaded holes for the location of eye bolts for mounting.

Bearing structure:single row cylindrical roller bearing

Single row cylindrical roller bearings, NU seires , N series , NJ series and NUP type

Quality standard:GB307 Rolling bearing technical requirement

Bearing factory model:Z-527249.ZL

China Bearing old type: 527249P5

Bearing boundary Dimension:

Standard size,offer drawing to confirm

ID(inner diameter)/:

Standard size,offer drawing to confirm

OD(outer diameter):

Standard size,offer drawing to confirm

Width/Height/thickness:56mm

MOQ:4PCS

Basic dynamic load rating, Radial Cr:610KN

Basic static load rating, Radial Cor:1250KN

Load Direction:Radial Bearing

Bearing boundary inch size:

Standard size,offer drawing to confirm

Bearing outer diameter inch:

Standard size,offer drawing to confirm

Bearing inner diameter inch size:

Standard size,offer drawing to confirm

Bearing height inch:

Standard size,offer drawing to confirm

Weight:60KGS

Outer Ring material:Steel GCr15SiMn

Inner Ring material:Steel GCr15SiMn

Precision grade:P5 P6 grade

Radial clearance:C1 C2 C3 Gruop available.

 The bearing working speed:1400rpm

 HS code:8482500090

Outer Ring and Inner Ring heat treatment:HRC55-62

Heat Treatment:Bainite heat treatment

Cage material:Brass cage

Trademark:JHB or OEM

The seaport name:Shanghai or Tianjin or qingdao seaport

Lubrication:Oil or Grease oil hole and oil groove in the outer ring

Transport Package Industrial Packing or as Per Requirement.

Mainly Market:America Europe Asia Africa

The bearing application: high speed wire cable steel rope tubular stranding machines
