Multifunctional high-voltage power supply
- 100 Set / Sets per Month
- shanghai
- Cash
You May Like
Product Details
| Brand Name | 躍遷 | Place of Origin | China | |
| Model Number | WD3 | Output Power | 500W | |
| Output Current | 500mA | Output Voltage | 0-50KV | |
| Input Voltage | 220V or 110V |
Product Description
500W high-voltage power supply, used for laboratory high-voltage testing, as a high-voltage source and other applications
Appearance parameters
Size: 185mm * 240mm * 290mm
Weight: 2000g
Main technical parameters
1. Product name: High voltage regulated power supply (constant current power supply)
2. Product model: WD3 series
3. Product Brand: Leap Forward
4. Input voltage: AC 220V ± 10%
5. Output parameters
Power: 500W (voltage * current=500VA)
Voltage (regulated power supply): 0-50KV (series parameters)
Current (constant current power supply): 0-500mA (series parameters)
Response speed: ≤ 1mS
6. Output regulation: ① Adjust the output voltage (regulated power supply) by the voltage regulation knob
② Adjust the output current by the current adjustment knob (constant current power supply)
7. Operating Environment
Temperature: -10~+40 ℃
Humidity: ≤ 85%
8. Cooling method: air cooling
