4G DTU communication module RS485 RS232 TTL to 4G wireless data transmission terminal

Product Features

Watchdog anti downtime design

Anti surge and anti-static protection

Supports multiple transmission protocols

Satisfied the unmanned on-site communication needs

Support device cloud management platform

Enable transparent transmission of data information

Help enterprises quickly build industrial equipment networks

Hardware interface

RS485 data interface

RS232 data interface

TTL interface

Standard SAK-3.5EN (Phoenix Terminal)

Power input interface positive and negative ports

External reset interface, external pull-down to control reset

A standard SMA antenna connection port for 4G antennas

Product parameters

4G CAT4 network

Support network

Classification supports TDD-LTE, FDDLTE

Downward compatibility with GPRS networks

Supporting interfaces

Supports 1 set of RS485 interfaces

Supports 1 set of RS232 interfaces

Supports 1 set of TTL interfaces (cannot be used simultaneously with RS232 or RS485)

Supports interfaces and 1 external reset interface

Supports 1 SMA antenna interface

Supports 1 Mini SIM card holder (2FF large card)

Indicator light

3 status indicator lights

Supply voltage

DC 9V-25V

Size

111mm * 61mm * 28.4mm (length * width * height)

Weight

150g (including 4G rubber rod antenna)

Installation method

Supports hanging ears and rail clips (optional)

Network rate

FDD: 150Mbps (downstream)/50Mbps (upstream)

TDD: 130Mbps (downstream)/35Mbps (upstream)

Working current

Maximum peak to peak current 550mA/12V

Maximum average current 180mA/12V (with continuous data throughput)

Average standby current 30mA/12V (without continuous data throughput)

Temperature range

-30-80 degrees Celsius

Shell material

metal

4G CAT1 network

Support network

Classification supports TDD-LTE, FDDLTE

Downward compatibility with HSPA+and GPRS networks

Supporting interfaces

Supports 1 set of RS485 interfaces

Supports 1 set of RS232 interfaces

Supports 1 set of TTL interfaces (cannot be used simultaneously with RS232 or RS485)

Supports 1 external reset interface

Supports 1 SMA antenna interface

Supports 1 Mini SIM card holder (2FF large card)

Indicator light

3 status indicator lights

Supply voltage

DC 9V-25V

Size

111mm * 61mm * 28.4mm (length * width * height)

Weight

150g (including 4G rubber rod antenna)

Installation method

Supports hanging ears and rail clips (optional)

Network rate

FDD: 150Mbps (downstream)/50Mbps (upstream)

TDD: 130Mbps (downstream)/35Mbps (upstream)

Working current

Maximum peak to peak current 550mA/12V

Maximum average current 180mA/12V (with continuous data throughput)

Average standby current 30mA/12V (without continuous data throughput)

temperature range

-30-80 degrees Celsius

Shell material

metal

Application field

The VDLO5 series data transmission terminals are particularly suitable for large-scale equipment networking and information construction, such as charging station equipment, cameras, distribution automation, power meter reading, battery management, robots, field operation machinery, oil and natural gas exploration and extraction equipment, digital production equipment, and other machinery. Excellent hardware performance, multiple network access, easy deployment, and comprehensive remote management functions are shining brightly in the construction of equipment informatization.
