Honeywell ControlEdge? PLC

ControlEdge? PLC

1、Introduction

This document provides technical information for the Honeywell ControlEdgeTM PLC. Product details can be found in the Product Information Note. Detailed planning, installation and configuration information is available in the product user guides.

2、Overview

Honeywell’s advanced Programmable Logic Controller (PLC) technology improves control performance while offering greater flexibility and lower costs. The new ControlEdge? PLC improves integration with Experion?, HMIs and third-party devices,and reduces configuration efforts by utilizing the industry-accepted IEC 61131-3 programming languages, as well as remote configuration and firmware updates.

3、The key features of the ControlEdge PLC include:

? First PLC with HART enabled Universal I/O module for greater configuration flexibility

? ISASecure EDSA Level 2 certified cyber security capabilities improved safety of the plant and personnel

? Designed and developed by Honeywell, a global leader in process automation for more than 40 years

? Tightly integrated with Experion, Honeywell’s best-in-class Distributed Control System (DCS), Supervisory Control and Data Acquisition (SCADA) system, safety system and Experion Panel PC

? Tight integration with Honeywell’s market leading Field Device Manager - FDM

? Native controller redundancy

? Optionally redundant power supplies

? I/O racks of various sizes (1,4, 8 and 12 IO slots options)

? Three variants of power supplies: 51W 24VDC, 58W 110/240AC & 41W 110/240 AC (Extended Temperature)

? Leverages Honeywell’s LEAP? project methodology and Universal I/O for greater configuration flexibility

? Compatible with leading open network standards such as Modbus and OPC UA

? Built-in EtherNet/IP Protocol with both Server and Client, ODVA Certification

? Built-in PROFINET Protocol with PROFINET IO Controller

? Support DLR on EtherNet/IP Protocol Client and PROFINET IO Controller

? Support DNP3 Master and Outstation

? Support Serial Communication Module (2×RS232 ports, 2×RS485 ports) with User Defined Protocol

? Connects to Human-Machine Interface (HMI) through Modbus and OPC UA protocols

? Support MQTT with Sparkplug B

? Powerful IEC 61131-3 programming environment

? HART function block supporting all HART commands in PLC

? Support Removal and Insertion under Power for CPM and I/O modules

? Support Fail safe state configuration on output signal type

? Simulation support on standalone and on Virtual Engineering Platform

? Support Subsea application MDIS based on OPC UA

? Support Fault Tolerant Ethernet (FTE) network.

? Support communication to EUCN when CPM is working as ELMM. EUCN uses FTE as media.
